Important: our camera is can't work with DVR. WithSO-N-YCCD camera is better than CCD Camera.
6M AV plug cable as default ,Gps need leave a message
Notes: the frontlogo is default without guide line ,if you need guide line for logo camera ,please leave message to us,thanks.*Please check your car logo hole size whether the same as the camera size before you buy,thanks.
because in different contries,There may be different from the car model.
the front logocamera fits for City/Fit 2013 2014 2015
Cable decription:
Specification for car rear camera
Image sensor
1/3" Color CCD(default) for 1/3" CCDSONY Color
Signal system
NTSC/PAL(NTSC will be sent as default ,if you need PAL , please leave message to us, thanks)
Horizontal resolution
520 TV lines 600 TV lines
Effective pixels
720x480
728x512
Lens viewing angle wide angle
<;0.1LUX 0.05LUX
IP Rate IP67
Video output RCA, 1.0Vp - p,75ohm
Image pipeline features Auto exposure,AWB,AGC, Auto flicker detection and cancellation
Image Reverse Left-Right mirror
White Balance Automatically
AGC&BLC Automatically
S/Nratio Better than 48dB(AGC OFF)
Shutterspeed 1 / 60 - 1 / 15,000sec
Installation hung external
Power supply DC 12V
Current consumption 85-115mA
Material
plastic
Remarks
Color/Warterproof/Shockproof
Operating temperature
-20 to 70 degree Celsius,RH95%
Storage Temperature
-30 to 60 degree Celsius,RH95%
Main Features
1,High Clear , Night Vision,Water Proof, Plastic material.
2,wide degree view angle, very small, and easy for installing
3,Low illumination and fill light automatic, waterproof
4,Special Designed Forcameraeasy to install and run
5,Designed according to the license light hole install.
6,All you need is a screen and video input port.
wire camera:
1 x Car Rear View Camera
1 x6M video cable
1 x power supply cable
1 x user manual
Designed for Precise Fit: This dedicated car reversing camera is tailored to match the shape and mounting position of your vehicle, offering seamless integration without gaps or modifications It aligns with perfect specifications to maintain a clean and original look
Clear Visual Assistance: Featuring a wide viewing angle, this vehicle specific backup camera kit enhances visibility when reversing It helps eliminate blind spots, supports safer parking, and provides real-time footage to assist in navigating tight spaces more confidently
Clean OEM-Style Appearance: With a discreet and low-profile design, this custom fit rear view camera blends smoothly into the vehicle’s exterior It avoids bulky add-ons and maintains the streamlined styling of your car while adding valuable reversing functionality
Simple Wiring and Setup: This car model specific parking camera includes connectors and layout points designed for straightforward installation The integrated rearview camera upgrade simplifies the process and connects easily with compatible in-car display systems
