Steloproad 4 RJ45+1 SFP PoE Switch 5-ports

Overview：

This Mini Industrial 4 Port 10/100/1000Mbps Gigabit Ethernet Switch with SFP Port supports 10/100/1000Base-T and 100/1000Base-X SFP Port. The Ethernet port supports both half-duplex and full-duplex mode. This industrial Ethernet switch is designed to match the critical industrial standards. With reliable and simple operation against vibration and shock, and wide operation temperature range, it could match a variety of harsh environment.

Features:

► 4-port 10/100/1000BASE-T RJ45 with auto-MDI/MDI-X function.

► 1 SFP Port, 100Base-FX or 1000Base-X dual mode (auto detection).

► Supports auto-negotiation and 10/100Mbps half/full duplex and 1000Mbps full duplex.

► Support DC 12V~48V wide range voltage input with built-in voltage booster.

► Standard: IEEE802.3 10Base-T Ethernet, IEEE802.3u 100Base-TX Fast Ethernet, IEEE 802.3x flow control.

► Complies with IEEE 802.3az Energy Efficient Ethernet (EEE).

► Industry standard design, dust proof and close design IP40, rugged high-strength metal case.

Specifications:

• Standard: IEEE802.3 10Base-T Ethernet, IEEE802.3u 100Base-TX Fast Ethernet, IEEE 802.3x flow control
• Casing Material: Aluminum Case
• Input Power: 12~48V DC (Terminal Block)
• Packet Buffer Memory: 1Mbits
• Max Packet Length: 9K Bytes
• Switch Capacity: 10Gbps/non-blocking
• Transmission Distance: up to 20KM
• Power Consumption: <6W
• Dimensions (WxDxH): 90 x 70x 29mm(3.74 x 2.76 x 1.15in)
• Weight: 250g(0.55lb)
