SMSL AO300 - Class D 2.1-channel 165W x 165W

SMSL AO300 Multifunction Class D Amplifier & DAC Headphone Amplifier SMSL AO300 HiFi Power Amplifier is a high quality audio device that uses the MA5332MS power amplifier chip and CS43131 decoding headphone amplifier chip. It delivers an impressive output power of 165W x 165W and supports 2.1-channel active audio and subwoofer output to enjoy high-quality sound with minimal distortion. Model: SMSL AO300. Input: HDMI (ARC)/RCA/BT/USB/Optical/Coaxial THD+N: 0.003% SNR: 107 dB. Channel separation: 98 dB. Input sensitivity/input impedance: 280mW/22kΩ. Output power: stereophonic 165W x2 (4Ω) / 85W x2 (8Ω). USB transmission: USB 2.0 (synchronous transfer). USB compatibility: Windows 7/8/8.1/10/11, Mac OSX, Linux MOA decoder: USB/Optical/Coaxial MQA CD Decoder: Optical/Coaxial Bit depth: USB 1bit, 16-32bit. Optical/coaxial 1bit, 16-24blt. Sample Rate USB PCM: 44.1-768kHz. DSD: 2.8224-11.2896 MHz. Optical/coaxial PCM: 44.1-192kHz. DSD: DSD64 (DoP). Power consumption: 40W (normal volume). Dimensions: 219 x 42 x 185 mm (W x H x D). Weight: 1.52 kg/3.35 lbs. List of accessories: 1 x AO300. 1 x AC cable. 1 x USB cable. 1 x HDMI cable. 1 x remote control. 1 x Bluetooth antenna. 1 x user manual. 1 x product card
