Samsung 970 EVO Plus - 1TB M.2

Best offer
AED
74589

Key Features

  • NAND flash type: MLC (Multi Level Cell)
  • NVMe version: 1.3
  • Random read (4KB): 600000IOPS
  • Random write (4KB): 550000IOPS
  • DevSlp (device sleep) support: Yes
  • Component for: PC
  • IEEE 1667: Yes
  • Active garbage collection: Yes
  • Power consumption DevSlp (device sleep): 5mW
  • M.2 SSD size: 2280 (22 x 80 mm)
  • TCG Opal 2.0: Yes
  • Opal SSC 2.0: Yes
  • S.M.A.R.T. support: Yes
  • Power consumption (idle): 0.003W
  • Power consumption (average): 6W
  • Offers
  • Price History
  • Specifications
  • Product Details
  • Review IconReviews

Specifications

Features

Launch date
4/16/2018
Mean time between failures (MTBF)
1500000 h
Bundled software
Magician Software for SSD management
Protection features
Temperature proof
Security algorithms
256-bit AES
Controller type
Samsung Phoenix
Product colour
Black
S.M.A.R.T. support
✓
Power consumption (idle)
0.00 W
TCG Opal 2.0
✓
Opal SSC 2.0
✓
Active garbage collection
✓
IEEE 1667
✓
Component for
PC
DevSlp (device sleep) support
✓
NAND flash type
MLC (Multi Level Cell)

Packaging data

Package type
Box

Weight & dimensions

Weight
8 g
Height
22.10 mm
Depth
2.38 mm
Width
80.20 mm

Power

Operating voltage
3.30 V
Power consumption (max)
9 W
Power consumption (average)
6 W
Power consumption (read)
6 W
Power consumption (write)
5.70 W
Power consumption DevSlp (device sleep)
5 mW

Other features

TBW rating
600
PCI Express interface data lanes
x4

Storage

NVMe
✓
SSD form factor
M.2
SSD capacity
1000 GB

Ports & interfaces

Interface
PCI Express 3.0

Operational conditions

Operating temperature (T-T)
0 - 70 °C
Operating relative humidity (H-H)
5 - 95 %
Non-operating vibration
20 G
Non-operating shock
1500 G
Operating shock
1500 G
Storage relative humidity (H-H)
5 - 95 %

Technical details

Compliance certificates
RoHS

Security

TRIM support
✓
Hardware encryption
✓

Logistics data

Harmonized System (HS) code
84717070

Solid state drive

Read speed
3500 MB/s
Write speed
3300 MB/s
Memory type
V-NAND MLC
M.2 SSD size
2280 (22 x 80 mm)
Random write (4KB)
550000 IOPS
Random read (4KB)
600000 IOPS
NVMe version
1.3

Product Details

High-performance, highly reliable NVME M.2 SSD featuring exceptionally fast sequential speeds and outstanding endurance. At a Glance Featuring our latest V-NAND technology and a newly enhanced Phoenix controller, Samsung 970 EVO Plus Series NVMe M.2 SSDs deliver outstanding performance in Non-Volatile Memory Express (NVMe), with exceptionally fast sequential speeds outperforming our standard 970 EVO models. Plus, Samsung's Magician software solution provides advanced functionality for you to manage, monitor and maintain your drive. - NVMe speeds up sequential read/write performance, while Samsung TurboWrite technology accelerates write speeds even further - Compact M.2 form factor ready for high-end computing - Samsung Magician software for SSD management, including automatic firmware updates - Ideal for high-performance client PC applications (not designed for server or data center applications and warranty does not support such usage) Non-Volatile Memory Express (NVMe) 970 EVO Plus 1TB NVMe SSDs with a newly enhanced Phoenix controller outperform our standard 970 EVO 1TB model with exceptionally fast sequential read/write speeds up to 3,500/3,300 MB/s. They also support PCI Express® (PCIe) Gen 3 x 4 lanes to provide high bandwidth and low latency, making them perfect for business professionals who need cutting edge-performance for high-end computing. TurboWrite Technology Samsung’s intelligent TurboWrite technology helps to maximize your computing ability, accelerating write speeds above and beyond the already exceptionally fast speeds of NVMe. Dynamic Thermal Guard This feature constantly monitors and works to maintain ideal temperatures to protect the integrity of your data and safeguard from overheating. When temperatures rise above an optimal threshold, the Dynamic Thermal Guard automatically throttles them down to protect data while maintaining responsiveness. Professional-Quality Drive Management With the Samsung Magician software solution, you get advanced functionality to manage, monitor and maintain your 970 EVO Plus SSDs. Magician provides personalized firmware checking and additional functions tailored for individual drives. It even updates the firmware automatically to make sure that the drive's performance stays up to date. V-NAND Technology Samsung's proprietary V-NAND flash memory helps to overcome the limitations of conventional planar NAND architecture. It stacks 64 cell layers vertically over one another rather than trying to fit itself onto a fixed horizontal space, in order to provide high density and performance with a small footprint. SSD Data Security This Drive includes an AES-256-bit hardware based, full disk encryption engine that secures your data without sacrificing performance and is compliant with TCG/OPAL V2.0 and IEEE1667. Highly-Efficient Power Management Thanks to exceptionally low active power consumption, you can work efficiently for long periods of time. Device Sleep Mode is also supported for ultra-thin laptop PCs and high-end desktop main boards. Samsung SSD Components Samsung's solid state drives are built entirely from Samsung components, leveraging our extensive OEM expertise to allow complete, optimized integration.

Files

Product Brochure

mmo_53912206_1524744750_8121_7302.pdf

PDF• 440.5 KB

Images


Reviews

Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...
Loading...

Join our newsletter

Be the first to know about new arrivals, sales, and exclusive picks

Sign in to unlock newsletter access and stay in the loop

Allware
info@allware.com
+971522500911
World technology awards winner badge

Allware

  • About Us
  • Terms And Conditions
  • Privacy Policy
  • Contact Us

Partners

  • Why become a partner?
  • How to list your Online Shop?

Newsletter

  • Subscribe

Info

  • How Allware works
All Rights Reserved.
Please enable location access or select an emirate
-
00:00:00
Prayer timings

SSD capacity

Offers (4)

Amazon logo

2 offers

From
AED
745

Samsung (MZ-V7S1T0B/AM) 970 EVO Plus SSD 1TB - M.2 NVMe Interface Internal Solid State Drive with V-NAND Technology

Black
AED
74589
geekay

1 offer

From
AED
Infinity

Samsung 970 EVO Plus 1TB NVMe M.2 Internal SSD PC

Unavailable
Noon logo

1 offer

From
AED
Infinity

Samsung 970 EVO Plus M.2 Internal Solid State Drive 1 TB

Unavailable

Price History

Price History Skeleton
Price History Shimmer Effect
Loading price history...

Similar Products

See all
-36%
Western Digital SN850P - 2 TB M.2

Western Digital SN850P - 2 TB M.2

AED
1 19900
AED
75900
8 offers
Kingston Technology NV3 - 1TB M.2 2280

Kingston Technology NV3 - 1TB M.2 2280

AED
47453
5 offers
Western Digital SN850 - 2TB M.2 2280

Western Digital SN850 - 2TB M.2 2280

AED
79900
5 offers
Samsung 980 PRO - 1TB M.2

Samsung 980 PRO - 1TB M.2

AED
49900
9 offers
Samsung 980 - 1 TB

Samsung 980 - 1 TB

AED
41900
9 offers
-27%
Crucial P3 - 500GB M.2

Crucial P3 - 500GB M.2

AED
22200
AED
16125
8 offers
Lexar NM620 - 1 TB M.2 2280

Lexar NM620 - 1 TB M.2 2280

AED
45713
8 offers
Western Digital SN770M

Western Digital SN770M

AED
42289
8 offers
-52%
Samsung 980 PRO - 2000 gigabyte M.2

Samsung 980 PRO - 2000 gigabyte M.2

AED
1 76300
AED
83000
7 offers
Samsung 990 Pro Series - 1 TB M.2

Samsung 990 Pro Series - 1 TB M.2

AED
64900
7 offers

More from Samsung

See all
Samsung (Renewed) RAM8 - 8 GB 2666 Mhz DDR4

Samsung (Renewed) RAM8 - 8 GB 2666 Mhz DDR4

Unavailable
1 offer
Samsung Enzo Aramid Case for Galaxy S25 Ultra

Samsung Enzo Aramid Case for Galaxy S25 Ultra

AED
29900
1 offer
-18%
Samsung (Renewed) Galaxy Note 9 N960U - 6GB 128GB

Samsung (Renewed) Galaxy Note 9 N960U - 6GB 128GB

AED
1 26150
AED
1 03209
3 offers
-15%
Samsung (Renewed) QA65QN80FAUXZN - 65 INCH

Samsung (Renewed) QA65QN80FAUXZN - 65 INCH

AED
4 13825
AED
3 49900
1 offer
Samsung Galaxy Tab S8+ - 128GB 12.4"

Samsung Galaxy Tab S8+ - 128GB 12.4"

AED
1 64900
36 offers
Samsung (Renewed) 65Q70T - 65 inch

Samsung (Renewed) 65Q70T - 65 inch

Unavailable
1 offer
Samsung 65CU8000 - 65 inch

Samsung 65CU8000 - 65 inch

AED
1 59800
7 offers
Samsung QA85LS03AAUXZN - 85 Inch

Samsung QA85LS03AAUXZN - 85 Inch

Unavailable
1 offer
Privacy Screen Protector for Samsung Tab S9+
