Revotech USB0502G - 37V - 57V 5V/2.4A 1 output RJ45 port 10/100/1000Mbps IEEE802.3af 12.5W

Overview: USB0502G PoE splitter is a new model: With RJ45 port and Micro USB Port. It is a PoE remote power equipment base on IEEE802.3af standard and can separate the power and data via cable transmission. Proper matching use with POE switch or PSE injector which meet standard IEEE802.3af, provides power and data at the same time for the terminal device does not support PoE. POE switches or POE power supplies generally need to maintain a minimum 10mA current load in order to stably output 48V. If the load is not detected to be lower than 10mA in 400-500ms, light load protection will appear. If no load is connected, the 48V output will be cut off. Specifications: Support international standard IEEE802.3 af(12.5W); POE port Support 10/100/1000Mbps data transmission PD support 37V - 57V voltage transmission, Automatically detects power supply from PSE power supply module 5V/2.4A power output using Micro USB, the Micro USB port only for power-charging. Support the isolation circuit protection, can effectively protect electrical equipment. Support the short circuit, overvoltage protection, light load protection, Overload protection 1500V high voltage isolation Model: USB0502G Transfer Rate: 10/100/1000Mbps(Gigabit) Power: Input 48V DC /0.35A, Output 5V/2.4A Standard: IEEE802.3 af(12.5W) TRNF: 1/2(+),3/6(-);4/5(+),7/8(-) Interface Type: 1 Input RJ45 port, 1 output RJ45 port, 1 DC output（Micro USB） Standard: IEEE 802.3 I, IEEE 802.3 u, IEEE 802.3 x, IEEE 802.3 af LED: Yellow PoE lamp Temperature: Work within -20~50°,Storage within -30~60° Humidity: Work within 10%~90% (Non-condensing), Storage within 5%~95% (Non-condensing) Dimension: 27.5cm x 2.8cm x 2.3cm Weight: 0.05kg Package Content: 1 x POE Splitter (USB0502G)
