Compliance certificates: CE, Federal Communications Commission (FCC), RoHS, UKCA, VCCI
TRIM support: Yes
Hardware encryption: No
Memory type: 3D NAND
Read speed: 3500MB/s
Write speed: 1700MB/s
Specifications
Features
Mean time between failures (MTBF)
2000000 h
S.M.A.R.T. support
✓
Component for
PC/Laptop
Packaging data
Package type
Box
Package height
99 mm
Package depth
6.45 mm
Package width
100 mm
Weight & dimensions
Weight
6.60 g
Height
4 mm
Depth
22 mm
Width
80 mm
Performance
Maximum operating temperature
70 °C
Minimum operating temperature
0 °C
System requirements
Mac operating systems supported
Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supported
Windows 10, Windows 7, Windows 8, Windows Vista, Windows XP
Other features
TBW rating
800
PCI Express interface data lanes
x4
Storage
RAID support
✓
NVMe
✓
SSD capacity
500 GB
SSD form factor
M.2
Ports & interfaces
Interface
PCI Express, PCI Express 3.0, PCI Express 4.0
Operational conditions
Operating temperature (T-T)
0 - 70 °C
Technical details
Certification
BSMI, CE, FCC, KCC, REACH, RoHS, VCCI
Compliance certificates
CE, Federal Communications Commission (FCC), RoHS, UKCA, VCCI
Memory
ECC
✓
Security
TRIM support
✓
Hardware encryption
✗
End-to-End Data Protection
✓
Logistics data
Harmonized System (HS) code
84717070
Solid state drive
Memory type
3D NAND
Read speed
3500 MB/s
Write speed
1700 MB/s
M.2 SSD size
2280 (22 x 80 mm)
NVMe version
1.4
Product Details
CS3030 SOLID STATE DRIVES
The PNY XLR8 CS3030 M.2 NVMe SSD is an excellent choice for an NVMe upgrade from a SATA based solid state drive (SSD) in an existing NVMe enabled PC or MAC desktop or laptop computer. The CS3030 drive is designed to be a high performance SATA SSD replacement to help realize faster boot times, quicker application launches, and better overall system performance. Do more in less time with NVMe; boot up, power down, and load applications up to 6 times faster than with SATA based SSD’s. With no moving parts, the PNY XLR8 CS3030 M.2 NVMe SSD is highly durable, less likely to fail, and supports up to 5 years of warranty.
The PNY XLR8 CS3030 M.2 NVMe Solid State Drive is the ideal solution to upgrade from a SATA based solid state drive (SSD) in an existing NVMe enabled PC or Mac desktop or laptop computer. The NVMe interface delivers exceptional performance of up to 3,500MB/s seq. read and 3,000MB/s seq. write speeds. It is designed to be a high performance SATA SSD replacement to help realize faster boot times, quicker application launches, and better overall system performance. With no moving parts, the PNY XLR8 CS3030 is highly durable, less likely to fail, and supports up to 5 years of warranty.
The PNY XLR8 CS3030 is engineered with the same level of quality and durability that our consumers have enjoyed with the CS900 and CS1311 SSDs. We've taken the world's most advanced NAND flash and refined the CS3030 to achieve a higher threshold for endurance and reliability. PNY's extensive testing and rigorous validation process ensures compatibility across various platforms and multiple operating systems.
