MKHFP F-8200 - RJ11 RJ45

Features: * Track and locate RJ45 (same SPP / 4 -Core), RJ11 cables. * Anti-jamming, able to work on exchanger and PC boot. * Measure cable length for RJ45, RJ11 cable accurately. * Check open, short, cross, crosstalk for RJ11, RJ45 cable. * Accurately locate the breaking point. * Memory function for calibration data. * Headphones allow use in noisy environments. Technical indices: F-8200 Transmitter Specifications LCD Screen 53x25mm Tonal frequency 130kHz The max. Distance of electrified wire tracing cable: 3000m Non-electrified wire: 2000 m The max. Distance from cablemapping 2000m The max. Distance of cable length tests 1000m Cooneucated trace cable to change anti-jamming 2 Tone Tone Mode, Adjustable Compatible with RJ11, RJ45 connectors LED Lights Display WIRMAP, TONE, TRACING key LCD Cable Card Indication (#1- #8) LCD shielded indication (#9) Low battery display LCD (6.5V) Battery Type 1. 5 V AA battery x 4. Dimensions (LXWXD) 185 x 80 x 32 mm NF-8200 Receiver Specifications Frequency 130kHz The max. Working current less than 70mA Earphone Jack 1 LED Illumination 2 LE Ds Battery type DC9.0V (NEDA 1604 / 6F22 DC9V) x 1 piece. Dimensions (LXWXD) 218 x 46 x 29 mm NF-8200 Remote Unit Specifications Compatible with RJ11, RJ45 connectors Dimensions (LXWXD) 107 x 30 x 24 mm
