Micron CT51264BF160B - 4GB 1600 MHz SODIMM DDR3

Name: Micron CT51264BF160B - 4GB 1600 MHz SODIMM DDR3
Brand: Micron
SKU: 430047
Availability: InStock

Best offer

AED

120⁵⁰

AED

130¹⁶

-7%

Key Features

Component for: PC/Server
SPD profile: Yes
Module configuration: 512M x 8
CAS latency: 11
Memory ranking: 1
Internal memory: 4GB
Compliance certificates: RoHS
Memory clock speed: 1600MHz
Internal memory type: DDR3L
Memory form factor: 204-pin SO-DIMM
Product colour: Green
ECC: No
Width: 67.8mm
Depth: 3.8mm
Height: 30.1mm

Specifications

Features

Internal memory

4000 MB

Product colour

Green

Module configuration

512M x 8

CAS latency

Memory ranking

SPD profile

✓

Component for

PC/Server

Weight & dimensions

Height

30.10 mm

Depth

3.80 mm

Width

67.80 mm

Computer system

Internal memory

4 GB

Operational conditions

Operating temperature (T-T)

0 - 95 °C

Technical details

Doesn't contain

Halogen

Compliance certificates

RoHS

Memory

ECC

✗

Memory clock speed

1600 MHz

Internal memory type

DDR3L

Memory form factor

204-pin SO-DIMM

Product Details

Features: - DDR3L functionality and operations supported as - defined in the component data sheet - 204-pin, small-outline dual in-line memory module (SODIMM) - Fast data transfer rates: PC3-14900, PC3-12800, or PC3-10600 - 1GB (128 Meg x 64), 2GB (256 Meg x 64), 4GB (512 Meg x 64) - VDD = 1.35V (1.283–1.45V) - VDD = 1.5V (1.425–1.575V) - Backward compatible with standard 1.5V (±0.075V) DDR3 systems - VDDSPD = 3.0–3.6V - Nominal and dynamic on-die termination (ODT) for data, strobe, and mask signals - Single rank - Fixed burst chop (BC) of 4 and burst length (BL) of 8 via the mode register set (MRS) - On-board I2C serial presence-detect (SPD) EEPROM - Gold edge contacts - Halogen-free - Fly-by topology - Terminated control, command, and address bus
