KLUOFCO ETCR4700 - 35mm×40mm

Power DC9V alkaline batteries(1.5V LR6×6) Consumption About 80mA at most with enabled backlight battery working continuously for about 10 hours About 5mA with disabled backlight battery working continuously for about 16 hours Display Mode LCD display 240dots×160dots Meter Size Length Width Height:196mm×92mm×54mm Clamp Size round current clamp:35mm×40mm Measurement Range (automatic shift) AC :0.00 V~600V (automatic shift) AC Current:0mA~400A (automatic shift) Phase:0~360° Frequency:45.00Hz~65.00Hz Active Power:0W~240kW Reactive Power:0W~240kVAR Apparent Power:0W~240kVA Power Factor:-1~+1 Current Vector Sum:0A~1200A Resolution :AC 0.01V Current:AC 1mA Phase:0.1° Frequency:0.01Hz Active Power:0.1W Reactive Power:0.1VAR Apparent Power:0.1VA Power Factor:0.001 Current Vector Sum:0.1A Phase Sequence Phase Sequence:U1、U2、U3 or I1、I2、I3 cursors blink in from left to right Phase Sequence:U1、U2、U3 or I1、I2、I3 cursors blink in from right to left SampleRate About 2 times/second Data Hold Press?HOLD?key to keep data "DH" symbol appears Data Storage 500 sets RS232 Interface USB-RS232 interface download data to computer for analysis and management Automatic Shutdown Automatic shutdown about 15 minutes later after launching to reduce battery consumption Backlighting Suitable for dark place and nightly use Detection ?Low battery symbol \u201c???? " appears to remind the replacement of battery when the battery drops below 7.2V. Weight Main Unit about 550g ,acuminate current clamp about 170g×3 round current clamp about 185g×3 test line about 250g Test Line Length 1.5m Current Clamp Length
