ESP32 Ethernet Adapter - 50 V 802.11 b , g , n 150 Mbit

klarako ESP32 Ethernet Adapter - 50 V 802.11 b , g , n 150 Mbit

Name: klarako ESP32 Ethernet Adapter - 50 V 802.11 b , g , n 150 Mbit
Brand: klarako
SKU: 1282007

Best offer

AED

184⁰⁰

AED

200⁰⁰

-8%

Specifications

Product Details

Specification: Item Type: Ethernet Adapter Hardware Material: for circuit board Color: As shown Weight: Approx. 31 g Chipset: ESPRESSIF ESP32 WROOM , LAN8720A Ethernet Chip , SI 3404 Power Management Chip Flash: 4 MB pSRAM: 8 MB SRAM: 520 kB SRAM Key: BOT , rest External device: Small memory card slot , USB C interface , PA2369NL 1825 S transformer , Ethernet POE interface HR861153C USB to TTL: CP2104 Modular interface: memory card , UART , SPI , I2C , PWM , I2S , ADC Clock: 32.768 MHz crystal oscillator Operating temperature range: 40 ° C + 85 ° C Power supply input: Type C 5 V , HR861153C Ethernet POE interface 50 V Working voltage: 2.7V 3.6V Maximum output current: About 1.2A Charging current: 500mA Interface: Type C Package List: 1 x Ethernet adapter 1 x pin
