Huawei H352-381

The 5G CPE H352-381 is a wireless 5G gateway for multiple users in households or small household office environments. It allows users to access the Internet. The H352-381 supports 3GPP Release 16 with LTE UE Downlink Category 20 and Uplink Category 13. The supported service functions are as follows: 5G SA NR: Downlink maximum 3CC (300M), 4x4 MIMO, 256 QAM, peak rate: 5.4 Gbps (DL/UL subframe configuration 8:2).Uplink maximum 2CC (200M) 2x2 MIMO, 256 QAM, peak rate: 5000. Mbit/s (DL/UL Subframe Configuration 8:2)NSA NR: Downlink Max 2CC (200M), 4x4 MIMO,256QAM, Peak Rate: 3.6Gbps (DL/UL Subframe Configuration 8:2)Uplink 1CC (100M), 1Tx, 256QAM, Peak Rate E125 Mbps (DL/UL subframe configuration 8:2) LTE: Downlink max 4CC, 4x4 MIMO (different frequency bands support different MIMO modes), 256 QAM, peak rate: 1.6Gbps (FDD frequency bands, 20+20+20+20MHz, 4x4MIMO, maximum 16 streams).Uplink 1CC, 1Txx1TxQAM, peak rate: 75 Mbps (FDD frequency bands, 20 MHz)

• Only 4G: downlink maximum 5CC, 4x4 MIMO (different frequency bands support different MIMO modes), 256 QAM, peak rate: 2Gbps (FDD frequency bands, 20+20+20+20+20MHz, 4x4MIMO, maximum 20 streams).Uplink 2CC, 1Tx, 64QAM, peak rate: 15. 0 Mbit/s (FDD frequency bands, 20+20 MHz). The actual data rate varies depending on the network configuration.

• LTE: B1/ B3/ B5/ B7/ B8/ B18/ B19/ B20/ B26/ B28/ B32/ B34/ B38/ B39/ B40/ B41/ B42/ B43WLAN: 2.422GHz-2.482 GHz, WiFi is only used for user installation and configuration. If the user accesses the Internet via this WiFi, the performance cannot be guaranteed. First connect the indoor router to the H352-381 and then connect the WiFi of the indoor router to access the internet
