HPE AP-314

Name: HPE AP-314
Brand: HPE
SKU: 348298
Availability: InStock

Best offer

AED

2 111⁶⁶

Key Features

2.4 GHz: Yes
5 GHz: Yes
Maximum data transfer rate (2.4 GHz): 300Mbit/s
Maximum data transfer rate (5 GHz): 1733Mbit/s
Number of SSID supported: 16
Antenna gain level (max): 5.7dBi
Maximum data transfer rate: 2033Mbit/s
Number of connectors: 4
Antenna connector type: RP-SMA
Placement: Ceiling, Wall
Wi-Fi Multimedia (WMM)/(WME): Yes
Internal: No
Antenna type: External, Internal
Cabling technology: 10/100/1000Base-T(X)
Auto MDI/MDI-X: Yes

Specifications

Features

Antennas quantity

Security algorithms

802.1x RADIUS, Not supported, WEP, WPA, WPA2, WPS

MIMO

✓

Product colour

White

Antenna gain level (max)

5.70 dBi

Maximum data transfer rate

2033 Mbit/s

Number of connectors

Antenna connector type

RP-SMA

Placement

Ceiling, Wall

Maximum data transfer rate (5 GHz)

1733 Mbit/s

Maximum data transfer rate (2.4 GHz)

300 Mbit/s

5 GHz

✓

2.4 GHz

✓

Packaging data

Package weight

850 g

Package height

55 mm

Package depth

218 mm

Package width

223 mm

Weight & dimensions

Weight

650 g

Height

48 mm

Depth

180 mm

Width

182 mm

Power

Power consumption (typical)

12.70 W

Power consumption (max)

14.40 W

Power over Ethernet (PoE)

✓

Performance

Transmitting power

21 dBmW

Wireless LAN features

Wi-Fi Multimedia (WMM)/(WME)

✓

Other features

Cable lock slot type

Kensington

Design

Reset button

✓

LED indicators

Link, Power, Yes

Cable lock slot

✓

Internal

✗

Computer system

Antenna type

External, Internal

Packaging content

Quick start guide

✓

Network

Bluetooth

✓

Networking standards

IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11h, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3z

Cabling technology

10/100/1000Base-T(X)

Auto MDI/MDI-X

✓

Channel bandwidth

160 MHz

Ethernet LAN data rates

10, 100

MIMO type

Multi User MIMO

Ports & interfaces

USB connector type

USB Type-A

Ethernet LAN (RJ-45) ports

WAN connection

Ethernet (RJ-45)

USB 2.0 ports quantity

Operational conditions

Operating temperature (T-T)

0 - 50 °C

Operating relative humidity (H-H)

5 - 93 %

Technical details

Certification

CB Scheme Safety, FIPS/TAA, UL2043 plenum rating, Wi-Fi Alliance (WFA) certified 802.11a/b/g/n/ac, cTUVus

Spread spectrum method

DSSS

Security

Number of SSID supported

Logistics data

Harmonized System (HS) code

85176990

Radar

Modulation

16-QAM, 256-QAM, 64-QAM, BPSK, CCK, DSSS, OFDM, QPSK

Product Details

The Aruba 310 Series access points provide the fastest gigabit data speeds and superb user experience for mobile devices, Internet of Things (IoT) devices, and applications in dense office environments. These Wave 2 access points deliver multi-user MIMO (MU-MIMO) aware ClientMatch to boost network efficiency and support the growing device density demands on your network. These APs have an integrated BLE Beacon to remotely manage battery-powered Aruba Beacons. Also for improved network simplicity and security, Dynamic Segmentation automatically enforces real-time device-level access policies on Aruba wired and wireless networks.

Files

Product Brochure

mmo_32165093_1478882959_0887_1187.pdf

PDF• 417.2 KB

Aruba 310 Series Access Points

mmo_71497923_1566463011_6309_11813.pdf

PDF• 611.2 KB

QuickSpecs

mmo_71497923_1566463029_5373_31211.pdf

PDF• 176.3 KB
