Hanwha QND-8011

Unavailable

Key Features

Lens viewing angle, vertical: 76.7°°
Lens viewing angle, diagonal: 136.1°°
Fixed focus: Yes
Alert notification type: E-mail
Type: IP security camera
Active tampering alarm: Yes
Flip & mirror: Yes
Supported graphics resolutions: 1280 x 960, 1920 x 1080 (HD 1080), 2592 x 1944, 640 x 360, 640 x 480 (VGA), 720 x 480, 768 x 576, 800 x 448, 800 x 600 (SVGA)
Number of effective pixels (H x V): 2592 x 1944pixels
Form factor: Dome
Streaming method: Multicast, Unicast
Ethernet interface type: 10 Gigabit Ethernet, 100 Gigabit Ethernet
Ethernet LAN: Yes
Maximum aperture number: 2
Fixed focal length: 2.8mm

Specifications

Features

Card reader integrated

✓

Quality of Service (QoS) support

✓

Languages support

Simplified Chinese, Traditional Chinese, German, Dutch, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, SPA, Swedish, Turkish

Video motion detection

✓

Connectivity technology

Wired

Product colour

White

Video streaming

✓

Fixed focus

✓

Alert notification type

E-mail

Type

IP security camera

Active tampering alarm

✓

Flip & mirror

✓

Supported graphics resolutions

1280 x 960, 1920 x 1080 (HD 1080), 2592 x 1944, 640 x 360, 640 x 480 (VGA), 720 x 480, 768 x 576, 800 x 448, 800 x 600 (SVGA)

Weight & dimensions

Weight

165 g

Height

56 mm

Diameter

99 mm

Power

Power consumption (typical)

4 W

Power consumption (max)

5 W

Power source type

PoE

Performance

Number of effective pixels (H x V)

2592 x 1944 pixels

Other features

Noise reduction

✓

Storage

Compatible memory cards

MicroSD (TransFlash), MicroSDHC, MicroSDXC

Design

International Protection (IP) code

IP42

IK code

IK08

Housing material

Plastic

Placement supported

Indoor/Outdoor

Mounting type

Ceiling

Form factor

Dome

Network

Wi-Fi

✗

Bluetooth

✗

Networking standards

IEEE 802.1x

Supported network protocols

ARP, Bonjour, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, LLDP, NTP, QoS, RTCP, RTP(TCP), RTP(UDP), RTSP, SMTP, SNMPv1/v2c/v3(MIB-2), SSL/TLS, TCP/IP, UDP/IP, UPnP

Streaming method

Multicast, Unicast

Ethernet interface type

10 Gigabit Ethernet, 100 Gigabit Ethernet

Ethernet LAN

✓

Ports & interfaces

Ethernet LAN (RJ-45) ports

Operational conditions

Operating relative humidity (H-H)

0 - 90 %

Storage relative humidity (H-H)

0 - 90 %

Lens system

Maximum aperture number

Fixed focal length

2.80 mm

Video

Video compression formats

H.264, H.265, M-JPEG

Security

IP address filtering

✓

Camera

Day/night mode

✓

Gain control type

Manual

Back Light Compensation (BLC)

✓

Adjustment shutter speed

Manual

Bit rate control

Constant Bit Rate (CBR)/Variable Bit Rate (VBR)

Total megapixels

5 MP

Number of cameras

Sensor type

CMOS

Lens viewing angle, horizontal

104.4°

Progressive scan

✓

White balance

Indoor

Wide Dynamic Range (WDR)

✓

Alarm input/output

✓

Lens viewing angle, diagonal

136.1°

Lens viewing angle, vertical

76.7°

Shutter

Camera shutter type

Electronic

Pan-tilt unit

Tilt angle range

0 - 69 °

Pan range

0 - 350 °

Image sensor

Maximum resolution

2592 x 1944 pixels

Minimum illumination

0.15 lx

Product Details

Max. 5Megapixel (2592 x 1944) resolution 2.8mm fixed lens 0.15Lux (Color), WDR (120dB) Max. 30fps@5MP (H.265 / H.264) H.265, H.264, MJPEG codec support, Multiple streaming Tampering, Motion detection, Defocus detection Micro SD / SDHC / SDXC memory slot (Max. 128GB) Hallway view, WiseStream II support LDC, PoE

Files

Safety Data Sheet

mmo_72732133_1563888286_2304_14928.pdf

PDF• 242.4 KB

User manual

mmo_72732133_1563888295_9076_18643.pdf

PDF• 1.6 MB
