1. [HIGH-SPEED 4G INTERNET] Access high-speed 4G internet on smartphones and laptops.
2. [GLOBAL FREQUENCY SUPPORT] Compatible with various frequency bands worldwide.
3. [FUN CAMPING LIGHT] Has a colorful light for outdoor activities such as camping.
4. [EASY MONITORING] LED indicators for WiFi, and battery status.
5. [LONG-LASTING POWER] 10000mAh battery for long-lasting internet access on the go.
Specification:
Item Type: 4G CPE CAT6 Router
Material: Plastic
Size: Approx. 200x95x92 mm / 7.87x3.74x3.62 inch
SIM: Microsim x 1 (without)
Battery: Lithium cell 10000mAh (built-in)
Frequency band:
FDD: B1/B25 (B2)/B3/B66 (B4)/B26 (B5/B18/B19)/B7/B8B/B12 (B17)/B13/B20/B28/B71
TDD: B34/B38/B39/B40/B41 edge: 850/900/1800/1900
CA with frequency band aggregation function:
B1+B3/B26 (B5/B18/B19)/B7/B8/B20/B28
B2+BB2/B5/B12 (B17)/B13/B28/B 71
B3+B3/B5/B7/B8/B19/B20/B28
B4+B4/B5/B12 (B17)/B13/B28/B71
B5+ B5/B7/B40/B66
B7+B7/B8/B20/B28
B8+B38/B40/B41
B12+B66
B13+B6 6
B25+B25/B26
B26+B41
B40+B40
B41+B41
B66+B66/B71
WiFi Chipset: MT6631
WiFi: WiFi: 802.11 B/G/B/N/AC; 2.4G, 300 Mbps, 5.8 g, 866 Mbps
Encryption: WiFi Protected Access TM (WPA/WPA2) 2
Parameter:
LTE FDD-TDD: 3GPP Release9, Category 7, up to 300m DL and 86MBPS Ul at 20mhz 84.4 Mbps DL, Category 28; Up to 11.5 Mbps UL, Category 7
HSPA+: 3GPP Release10, up to 63.3 Mbps DL, Category 29; Up to 11.5 Mbps UL, Category 7
HSPA: 3GPP Release6, up to 7.2 Mbps DL, Category 7/8; up to 5.76 Mbps UL, Category 6
UMTS: 3GPP Release4, up to 384Kbps DL and UL
EDGE: 3GPP Release4, Multislot Class 12, up to 237Kbps and 118Kbps UL
GPRS: 3GPP Release4, Multislot Class 10, up to 85.6 Kbps and 42.8 Kbps UL
Applies globally: Europe, Asia, Africa, South America, Latin America, Australia, Middle
LED indicator: LED indicator lights can intuitively indicate the working status of the device
battery level indicator (white light):
battery level ≤100%, white light flashing: continuous on
battery level ≤75%, white light flashing: continuous on
battery level ≤50%, white flash lights: Continuous, battery level, battery level, battery level ≤25%, battery level, battery level ≤25%, the battery level, the battery level ≤250,2000. White light flashing: Continuously on
WIFI indicator light: Shows the current WIFI connection status
signal indicator: Shows the current connection status (as described below)
Power indicator light: Shows the current power status (on or off)
Power button: Long press to turn on/off or wake up the device, (double click to switch between 2.4/5.8G WIFI)
Light button: Turn on/off light and Colored ambient light
Turn on/off: charge the battery or connect to the computer
External antenna port (TS9): Expandable external antenna, improves signal reception ability and environment
Battery level indicator: Shows the current battery level
Reset button: Long press for 5 seconds to restore factory settings
SIM card: Please use a MICROS card
Reset button: Long press for 5 seconds to restore factory settings
SIM card: Released: Please use a MICROS card
Reset button: Long press for 5 seconds to restore factory settings
SIM card LAN cable to access the Internet
DC port: DC power supply/charging (or C type power supply) 12V 1A
: Approx. 855G / 30.16 oz. Make sure that the connection between the computer\'s WiFi and the WiFi device is working correctly. 2. Open a web browser and enter the router IP address in the address bar. If the IP conflict with other IP addresses in the , update the automatic IP address.3. Enter the login password to access the management interface. The default username and password is admin.
Package List:
1 x Adapter
1 x User Manual
1 x Hanging Buckle
1 x Cable
1 x 4G CPE Cat6 Router (Without SIM Card, Built-in Battery)
Note:
The connection process depends on the system of each WiFi device, please follow the instructions to operate.
