The Digital LCR Meter is a versatile electronic instrument designed to measure inductance (L), capacitance (C), and resistance (R) with high precision. This handheld device is for both professionals and hobbyists who require accurate measurements in their projects. With its clear digital display, users can easily read results without any confusion, making it a practical choice for various applications. In addition to high accuracy, this meter features automatic measurement adjustment, which simplifies the process by selecting the appropriate range for you. The integrated calibration functions ensure that your measurements remain reliable over time, giving you peace of mind while working on your electronic components. Whether you're testing capacitors, inductors, or resistors, this LCR meter is a valuable tool for achieving consistent results. Specifications (as provided) Its primary functions include characterizing passive components, verifying specifications, and troubleshooting circuit issues.
The device provides precise measurements at various frequencies, helping engineers and technicians ensure the performance and reliability of electronic circuits.
Product selling points and features 1. Fully automatic ran design manual easy switching of capacitance, inductance and resistance
2. High resolution five digit digital display high precision 1%, capacitance 1pF, inductance 1uH, resistance 1
3. Manual reset button Error removal, convenient and accurate testing of small numerical element
4.MINI USB interface DC5V charging, built in lithium battery
5.USB computer driver convenient for data acquisition, professional electronic engineer engineering testing use
product parameters product model M4070 LCR tester
ran mode automatic
LCR measurement parameters main parameters L C R
clear function open circuit short circuit sweep clear
test frequency C 10 to 500Khz,L 10 to 360Khz
interface Mini USB (virtual serial port)
charging interface Mini USB (500 mA)
test method automatic LC and RC vibration
display 128*64 dot matrix LCD main and sub parameters display with backlight
calibration at the same time startup automatic calibration internal standard capacitor
fuse protection 200 mA
test level ran ~ 1.5Vrms
accuracy L 1% +1 word, C 1% +1 word, R 0.5+1 word
<; 3 times second, 100mF lar capacitance 30 seconds)
display ran C 0.000pF ~ 100.000mF,L 0.000uH ~ 100.00H,(LC test frequency) 0~900000 ,S(RC test time) 0000~99.999,R 0.00 ~ 10.000M
