DH-IPC-HFW1230S1P-S4

Dahua Technology DH-IPC-HFW1230S1P-S4

Best offer

AED

93⁹⁰

Key Features

Camera tilt control: Yes
Detect distance: 37.3m
Observe distance: 14.9m
Recognize distance: 7.5m
Camera pan control: Yes
Noise reduction technology: 3D noise reduction
Lens viewing angle, vertical: 57°°
Lens viewing angle, diagonal: 125°°
Identify distance: 3.7m
Fixed focus: Yes
Type: IP security camera
Mirror: Yes
Motion sensor: Yes
Supported graphics resolutions: 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080), 352 x 288, 640 x 480 (VGA), 704 x 480, 704 x 576
ROM capacity: 16MB

Specifications

Features

Web browser

✓

Internal memory

64 MB

Number of sensors

1

Connectivity technology

Wired

Product colour

White

Fixed focus

✓

Type

IP security camera

Mirror

✓

Motion sensor

✓

Supported graphics resolutions

1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080), 352 x 288, 640 x 480 (VGA), 704 x 480, 704 x 576

ROM capacity

16 MB

Detect distance

37.30 m

Packaging data

Package weight

340 g

Weight & dimensions

Weight

220 g

Diameter

70 mm

Length

162.60 mm

Management features

Management software

DSS

Power

Power consumption (typical)

4.30 W

Power source type

PoE

DC output voltage

12

Performance

Number of effective pixels (H x V)

1920 x 1080 pixels

Camera pan control

✓

System requirements

Mobile operating systems supported

Android, iOS

Other features

Noise reduction

✓

Ergonomics

Angle of rotation

360 °

Design

International Protection (IP) code

IP67

Housing material

Metal, Plastic

Placement supported

Indoor/Outdoor

Mounting type

Ceiling/Wall

Form factor

Bullet

Network

Wi-Fi

✗

Bluetooth

✗

Supported network protocols

ARP, DHCP, DNS, FTP, HTTP, HTTPS, IPv4, Multicast, NTP, RTP, RTSP, SMTP, TCP, UDP

Ethernet interface type

Fast Ethernet

Ethernet LAN

✓

Ports & interfaces

Ethernet LAN (RJ-45) ports

1

Operational conditions

Operating relative humidity (H-H)

0 - 95 %

Storage relative humidity (H-H)

0 - 95 %

Technical details

Certification

CE-LVD: EN60950-1CE-EMC: Electromagnetic Compatibility Directive 2014/30/EUFCC: 47 CFR FCC Part 15, Subpart B

Lens system

Maximum aperture number

2

Fixed focal length

2.80 mm

Identify distance

3.70 m

Noise reduction technology

3D noise reduction

Recognize distance

7.50 m

Observe distance

14.90 m

Video

Video formats supported

H.264, H.265, M-JPEG

Frame rate

30 fps

Smart IR

✓

Privacy masking

✓

Focusing

Closest focusing distance

0.50 m

Camera

Day/night mode

✓

Gain control type

Auto/Manual

Back Light Compensation (BLC)

✓

Adjustment shutter speed

Auto/Manual

Camera shutter speed

1/3-1/100000 s

Region of Interest (ROI) encoding

✓

Total megapixels

2 MP

Number of cameras

1

Sensor type

CMOS

Lens viewing angle, horizontal

105°

Progressive scan

✓

White balance

Natural

Wide Dynamic Range (WDR)

✓

Highlight Compensation (HLC)

✓

Digital Wide Dynamic Range (DWDR)

✓

Lens viewing angle, diagonal

125°

Lens viewing angle, vertical

57°

Camera tilt control

✓

Shutter

Camera shutter type

Electronic

Pan-tilt unit

Tilt angle range

0 - 90 °

Pan range

0 - 360 °

Image sensor

Maximum resolution

1920 x 1080 pixels

Minimum illumination

0.01 lx

Night vision

Night vision

✓

LED type

IR

Night vision distance

30 m

Number of illumination LEDs

1

Product Details

With features of simple installation, easy operation, and high performance-cost ratio, Dahua Entry Series camera is applicable to small and medium-sized scenes, such as homes/residences, small-sized retail stores, and other small and medium-sized enterprises.

Files

Product Brochure

mmo_87033438_1603703077_629_2705.pdf

PDF• 431.2 KB
