Cisco MS220-8 8-ports

Name: Cisco MS220-8 8-ports
Brand: Cisco
SKU: 347688
Availability: InStock

Best offer

AED

1 163³⁹

Key Features

Switch layer: L7
Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
DHCP features: DHCP client, DHCP server
Latency (1 Gbps): 2.5µs
Port mirroring: Yes
Switching capacity: 20Gbit/s
MAC address table: 8000entries
Jumbo frames support: Yes
Multicast support: Yes
Auto MDI/MDI-X: Yes
Spanning tree protocol: Yes
Copper ethernet cabling technology: 1000BASE-T, 100BASE-T, 10GBASE-T
10G support: No
Link aggregation: Yes

Specifications

Features

Mean time between failures (MTBF)

756000 h

Quality of Service (QoS) support

✓

On/off switch

✓

Security algorithms

802.1x RADIUS

Rack mounting

✗

Product colour

Silver

Switching capacity

20 Gbit/s

MAC address table

8000 entries

Jumbo frames support

✓

Multicast support

✓

Switch layer

Weight & dimensions

Weight

1100 g

Height

44 mm

Depth

220 mm

Width

230 mm

Management features

Firmware upgradeable

✓

System event log

✓

Power

AC input voltage

100 - 240 V

Power consumption (typical)

10 W

AC input frequency

47/63 Hz

Power consumption (max)

159 W

Power over Ethernet (PoE)

✗

Total Power over Ethernet (PoE) budget

124 W

Design

LED indicators

Yes

Packaging content

Manual

✓

Network

Networking standards

IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at

VLAN support

✓

Auto MDI/MDI-X

✓

Spanning tree protocol

✓

Copper ethernet cabling technology

1000BASE-T, 100BASE-T, 10GBASE-T

10G support

✗

Link aggregation

✓

Port mirroring

✓

Ports & interfaces

Fiber optic connector

SFP

SFP module slots quantity

Basic switching RJ-45 Ethernet ports type

Gigabit Ethernet (10/100/1000)

Basic switching RJ-45 Ethernet ports quantity

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

5 - 95 %

Technical details

Certification

RoHS

Switch type

Managed

Data transmission

Latency (1 Gbps)

2.50 µs

Security

MAC address filtering

✓

Broadcast storm control

✓

DHCP features

DHCP client, DHCP server

Product Details

Hardware platform - Voice and Video QoS. - Low noise, fanless. - Non-blocking switch fabric. - Ultra-reliable, includes lifetime warranty. Power over Ethernet (MS220-8P) - 802.3af (PoE) 15.4 W per port. - 802.3at (PoE+) 25.5 W per port. - Maximum PoE output: 124 W. - PoE available simultaneously on all ports. - Intelligent PoE power allocation based on device advertisement (LLDP). Cloud management - Visibility and control over thousands of ports. - Built-in multi site management. - Zero touch provisioning. Monitoring and diagnostics - Cable failure testing. - Gateway connectivity testing. - Real time troubleshooting tools. - Email and text message alerts.

Files

Product Brochure

mmo_18665214_1489087488_6735_11077.pdf

PDF• 1.2 MB
