Brilluxa Camera Switch - 720×576

Item Type: Cameras Image Switch Material: Metal, Plastic Remote Control Battery: CR2025 Button Battery, 165mA Video Input: 4-CH Input Video System: PAL/NTSC(automatic identification system, attention, connect the camera before power on, The equipment support system) Video Parameters: Resolution: 720×576, 25FPS, Vp-p:1.0V Impedance: 75Ω Video Interface: 4 inputs ( connector), 2 outputs ( connector) Control Mode Trigger Control: High Trigger/Remote control/ One key control Auto Display Mode: Auto display Various Modes Mirror OFF/ON Operating temperature: -10℃ to +65℃ Power Consumption Hosts Running: 2W; Power-Saving Mode: 1W Output Power: 12V / 0.8A (camera power supply) Rated Voltage: DC 12V/24V Parking Monitoring Parking monitoring starting voltage must be greater than 12.5V (car batteries generally 13-14V), then the battery power, and a fifth DIP switch to dial up sign Parking REC. With a power loss protection, voltage less than 11.5V off automatically enter the sleep state, when the voltage is restored back to normal will automatically open parking video surveillance state. Advantage: DVD and DVR Dual Output Intelligent automatic recognition NTSL / PAL system and displays split screen Automatic intelligent trigger control / manual control Overcurrent and overload protection electronic fuse, automatic recovery 9-36 V wide voltage which can provide a stable 12 volts to cameras Automatically start-up , shut-off and switches dvd screen Compact housing, low power consumption, designed intelligent energy-saving less than 2 watt for driving inhabits. Package List: 1 x Combiner 1 x U Disk 1 x Remote Control 4 x Harness 5 x Cable 1 x Manual
