Alpine HCE-C91C - 640 (H) × 480 (V) – approx. 0.30MP

The Alpine HCE-C91C is a high-clarity reverse camera designed to give drivers a reliable and wide view of the area behind their vehicle. With its angled factory-style design, this camera integrates seamlessly into most cars while providing enhanced visibility for safer reversing and parking.

It features automatic white balance, excellent low-light performance, and a 100° horizontal viewing angle, ensuring clear visuals day and night. Installation is simple thanks to its compact wiring system—just connect power and video

Technical Specifications

Power Requirements: 9–16V DC

Installation Angle: 15°

Operating Temperature: -20°C to +80°C

Image Sensor: CMOS (4:3 aspect ratio)

Signal Format: PAL

Image Output: 75Ω (1 ± 0.2Vp-p)

Field of View: Horizontal: 100° ± 5° and Vertical: 85° ± 5°

Pixel Count: 640 (H) × 480 (V) – approx. 0.30MP

Minimum Illumination: 2 Lux

Automatic Adjustments: Mirror image, white balance

S/N Ratio: 40dB

Power-On Time: 700ms

Image Stabilisation Time: 1.5s

Object Detection Range: 0.3m – 6m

Storage Temperature: -40°C to +90°C

Power Consumption: <1.5W
