1. LCD display: Smart SMD testers use an LCD screen with high setting, distance and intuitive, for which exact and stable measurements are guaranteed and are suitable for test applications for electronic components
3
3. Excellent service: This electronics component test takes over an imported system to ensure high accuracy, reliability and stability during the measurement, to reduce working errors and to improve the test performance
4. Many functions: operation of scan components, manual selection of the measuring modes; Data Top Management, OL overload indicator, low -voltage instructions, automatic switch function
5. PC housing: The test scale for Pince consists of PC material, which has a strong strength, wear and high security, thanks to which is suitable for different measurements
Technical dataification:
type: Smart SMD -ster
value:
Intervall: 300/3K/30K/300 kΩ, accuracy: ± (1%RDG+5dgt)
Area: 3 mΩ/30mΩ, accuracy: ± (2%RDG+5dgt)
Capacity:
Area: 3NF/30NF/300NF/3UF/30UF/300UF, accuracy: ± (3%RDG+5dgt)
Area: 3mf/30 MF, accuracy: ± (5%RDG+5dgt)
Diode:
Open -Circuit tension: 2.8 V, test current: 1ma
Battery: 1 x button cell (not included)
Size: approx. 4 x 17 cm / 1.6 x 6.7 inches
1. Automatic scan
After switching on the screen, the screen shows the scan in ---- a symbol that indicates that the measuring device is in automatic scan mode. Simply measure the tested component and the measuring device automatically determines the value, the diode or the capacity so that the measured value is displayed on the screen.
Note: If you measure the components on the printed printed plate, make sure that you switch off and unload the capacitor voltage.
2. Measurement of the resistant value
① In automatic scan mode, measuring range: 0.1 Ω- 3000 MΩ.
② In manual measuring mode, which was selected by the FunC key, the measuring range expands to 30 mΩ, namely 0.1 Ω-30.00 MΩ. After showing Ol after overload.
Note: This tester has no pipe measuring function. When choosing a pittile symbol with the FunC button, the function that measures the value of 300 Ω applies.
3. Capacity measurement
① In automatic scan mode measuring range: 0.3 NF-300.0UF.
② After entering the capacity measuring mode with the FunC key, the measuring area extends to 30.00 mf, namely 0.1 NF-30.00 MF.
Note: Make sure that you release the voltage on the capacitor before measuring to prevent electrical paralysis or damage to the measuring device.
4. Diodent test
① Discover the condition of the diodes and another conductive semiconductor units.
② When measuring the voltage trap forward, the R/C/D diode with the positive terminal of the tested component and the COM test pencil on the negative connection, the front tension trap is displayed on the screen.
5. Battery compensation:
If a symbol is displayed on the screen, it shows a low and requires a .
① Open a to open the battery cap.
② Remove the old and replace it with the correct technical dataification battery (3V key).
Packaging list:
1 x Smart SMD tester
1 x lid
Notification:
1. Check whether the house is damaged.
2. Check whether the test pencil is intact.
3. This tester cannot be driven as tweezers to prevent damage to the test pencil.
V.
5. Do not use a tester for objects in live status to avoid damage.
