LANCOM Systems 1780EW-4G

Name: LANCOM Systems 1780EW-4G
Brand: LANCOM Systems
SKU: 643855
Availability: InStock

Best offer

AED

5 605⁰⁰

Key Features

3G/4G USB modem compatibility: Yes
3G: Yes
4G: Yes
Firewall: Yes
WLAN data transfer rate (max): 867Mbit/s
ADSL: Yes
ADSL2: Yes
ADSL2+: Yes
Static route: Yes
Top Wi-Fi standard: Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bandwidth control: Yes
Guest access: Yes
Policy-based routing: Yes
Antenna design: External
Ethernet LAN interface type: Gigabit Ethernet

Specifications

Features

Country of origin

Germany

Antennas quantity

Authentication method

MS-CHAP and MS-CHAPv2 as PPP authentication mechanisms

VoIP protocols

SIP ALG

Quality of Service (QoS) support

✓

Number of WLAN connections (max)

512

Security algorithms

AES-CCMP, AES-GCMP, EAP, EAP-TLS, EAP-TTLS, PEAP, TKIP, WEP, WPA, WPA2

Maximum indoor range

30 m

Maximum outdoor range

250 m

MIMO

✓

Product colour

Grey

Access Control List (ACL)

✓

DHCP client

✓

DHCP server

✓

Product type

Tabletop router

Channels quantity

13 channels

Auto-sensing

✓

Port forwarding

✓

Multicast support

✓

Static route

✓

Packaging data

Package weight

1620 g

Package height

94 mm

Package depth

288 mm

Package width

385 mm

Weight & dimensions

Weight

600 g

Height

45 mm

Depth

140 mm

Width

210 mm

Management features

Web-based management

✓

Firmware upgradeable

✓

Bandwidth control

✓

Power

Power consumption (typical)

16.83 W

Power over Ethernet (PoE)

✓

Power source type

Performance

Load balancing system

✓

Top Wi-Fi standard

Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)

Wireless LAN features

Wi-Fi Multimedia (WMM)/(WME)

✓

Guest access

✓

WLAN data transfer rate (max)

867 Mbit/s

Other features

WLAN data transfer rates supported

12, 18, 24, 36, 48, 54, 6, 9

Filtering

✓

xDSL connection

✓

Filtering description

HTTPS, IP

Software

Firewall security

user-defined rules and notifications

Firewall

✓

Design

Reset button

✓

LED indicators

LAN, LTE, Power, WLAN, Yes

Packaging content

Manual

✓

Cables included

LAN (RJ-45)

Network

4G bands supported

1800, 2100, 800, 900

Networking standards

IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11e, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.11r, IEEE 802.11u, IEEE 802.11w, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az

Supported network protocols

ARP, BOOTP, DHCP, DNS, HTTP, HTTPS, ICMP, IP, NTP/SNTP, NetBIOS, PPPoE (server), RADIUS, RIP-1, RIP-2, RTP, SIP, SNMP, TCP, TFTP, UDP, VLAN, VRRP, proxy ARP

3G standards

HSPA, UMTS

2G standards

EDGE, GPRS

VPN tunnels quantity

Wi-Fi band

Dual-band (2.4 GHz / 5 GHz)

Cabling technology

10/100/1000Base-T(X)

Mobile network generation

Mobile network connection

✓

SIM card slot

✓

Ethernet LAN data rates

10, 100

GSM bands supported

1800, 850, 900

4G standard

LTE

Wi-Fi standards

802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)

Ethernet LAN

✓

URL filtering

✓

Automatic channel selection

✓

UMTS bands supported

900

Ethernet LAN interface type

Gigabit Ethernet

VPN Passthrough

✓

Policy-based routing

✓

Ports & interfaces

DC-in jack

✓

Ethernet LAN (RJ-45) ports

Ethernet WAN

✓

DSL features

VDSL

✓

ADSL2+

✓

ADSL2

✓

ADSL

✓

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

0 - 95 %

Protocols

Routing protocols

BGP4, LISP, OSPFv2, RIP-2

Security

IP address filtering

✓

MAC address filtering

✓

Antenna

Antenna design

External

Mobile network

✓

Logistics data

Harmonized System (HS) code

85176990

Customs product code (TARIC)

85176200

WAN connection

3G/4G USB modem compatibility

✓

Product Details

High-performance 4G LTE VPN router with LTE Advanced, Wi-Fi, and Gigabit Ethernet The LANCOM 1780EW-4G+ is a professional, high-performance VPN router with LTE Advanced of up to 300 Mbps and 867 Mbps Wi-Fi based on IEEE 802.11ac. It is ideal e.g. for providing mobile, high-speed access to company networks via a secure VPN connection, while at the same time supporting a Wi-Fi network. Alternatively, the Gigabit Ethernet port enables the device to operate with an external modem including LTE backup. On top of that, the support of SD-WAN for an automatic VPN- and VLAN configuration and SD-WLAN for an automatic Wi-Fi configuration via the LANCOM Management Cloud enables an extremely easy and efficient handling of your infrastructure. The right choice for secure, reliable and sustainable networking solutions "Made in Germany".
