Kioxia KBG40ZNS512G - 512GB M.2

Key Features

NVMe version: 1.2.1
Random read (4KB): 400IOPS
Random write (4KB): 430IOPS
Component for: Server/workstation
Data transfer rate: 64Gbit/s
PCI Express interface data lanes: x4
NVMe: Yes
SSD capacity: 512GB
SSD form factor: M.2
Hardware encryption: Yes
Memory type: BiCS FLASH TLC
Read speed: 3500MB/s
Write speed: 1050MB/s
Power consumption (max): 4.1W
Width: 22mm

Specifications

Features

M.2 key ID

Data transfer rate

64 Gbit/s

Component for

Server/workstation

Weight & dimensions

Weight

7.30 g

Height

2.23 mm

Depth

80 mm

Width

22 mm

Power

Operating voltage

3.30 V

Power consumption (max)

4.10 W

Other features

PCI Express interface data lanes

Storage

NVMe

✓

SSD capacity

512 GB

SSD form factor

M.2

Ports & interfaces

Interface

PCI Express 3.1, PCI Express 4.0

Operational conditions

Operating temperature (T-T)

0 - 95 °C

Operating relative humidity (H-H)

0 - 90 %

Non-operating vibration

20 G

Operating vibration

20 G

Non-operating shock

1500 G

Operating shock

1500 G

Security

Hardware encryption

✓

Solid state drive

Memory type

BiCS FLASH TLC

Read speed

3500 MB/s

Write speed

1050 MB/s

Random write (4KB)

430 IOPS

Random read (4KB)

400 IOPS

NVMe version

1.2.1

Product Details

The KIOXIA BG5 Series is a line-up of compact form factor NVMe SSDs with capacities up to 1,024 GB, and leverages a PCIe 4.0, NVMe 1.4 specification compliant interface and KIOXIA 112-layer BiCS FLASH 3D TLC (3-bit-per-cell) flash memory. With higher bandwidth, improved flash management and Host Memory Buffer (HMB) technology, BG5 Series SSDs deliver best-in-class read performance for compact form factor SSDs of up to 3,500 MB/s (sequential read) and up to 500K IOPS (random read), with active power consumption of up to 4.3 W (Typ.). KIOXIA BG5 Series SSDs are available in capacities of 256 GB, 512 GB and 1,024 GB in M.2 Type 2230 and Type 2280 module form factors, making them suitable for thin and light system designs, such as ultra-thin PCs, embedded devices and server boot in data centers. The KIOXIA BG5 Series offers a Self-Encrypting Drive (SED) model option, supporting TCG Opal Version 2.01.
