ASUS VP228HE - 90LM01K0-B05170 21.5 inch 1920 X 1080 pixels
Best offer
AED
28900
Key Features
- Display brightness (typical): 200, 250cd/m²
- USB Type-A downstream ports quantity: 1
- Thin client installed: No
- Flicker-free technology: Yes
- AMD FreeSync type: FreeSync
- Colour gamut standard: sRGB
- Aspect ratio: 16:9, 4:3
- Resolution: 1920 x 1080pixels
- Display: LCD, LED
- No flickering: Yes
- Display surface: Matt
- Brightness: 250cd/m²
- Supported graphics resolutions: 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1366 x 768, 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 832 x 624
- ECO mode: Yes
- Backlight type: LED
Specifications
Features
Country of origin
China
Safety
WEEE
Plug and Play
✓
3D
✗
Feet colour
Black
Viewable size, vertical
268 mm
On/off switch
✓
Viewable size, horizontal
476mm, 477mm
Digital vertical frequency
[object Object],[object Object],[object Object],[object Object],[object Object]
Digital horizontal frequency
[object Object],[object Object],[object Object]
Tilt adjustment
✓
Maximum refresh rate
60Hz, 75Hz
Product colour
Black
Audio input
No, Yes
Colour gamut standard
sRGB
Aspect ratio
16:9, 4:3
Resolution
1920 x 1080 pixels
Display
LCD, LED
No flickering
✓
Display surface
Matt
Brightness
250 cd/m²
Supported graphics resolutions
1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1366 x 768, 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 832 x 624
ECO mode
✓
Backlight type
LED
Display brightness (typical)
200cd/m², 250cd/m²
Packaging data
Package type
Box
Package weight
4100g, 4140g, 4200g, 4680g, 5200g, 5300g, 6100g
Package height
122mm, 130mm, 420mm, 440mm, 443mm, 468mm, 480mm, 568mm
Package depth
122mm, 123mm, 130mm, 132mm, 133mm, 148mm, 550mm, 558mm
Package width
420mm, 432mm, 480mm, 552mm, 565mm, 566mm, 576mm
Sustainability
European Product Registry for Energy Labelling (EPREL) code
364711, 364712, 388078
Weight & dimensions
Package weight
4.10kg, 4.14kg, 4.20kg, 4.68kg, 5.20kg, 5.30kg, 6.10kg
Weight (with stand)
2400g, 2900g, 3500g, 4100g
Height (with stand)
363mm, 373mm, 385.90mm, 386mm, 387.20mm
Depth (with stand)
199mm, 199.40mm, 200.60mm, 201mm, 210mm
Width (with stand)
490mm, 512.80mm, 513mm, 514.10mm, 514.90mm
Weight (without stand)
2400g, 2500g, 2860g, 2900g, 3100g, 3500g
Height (without stand)
298mm, 309mm, 385mm, 387.20mm
Width (without stand)
490mm, 512.80mm, 513mm, 514mm, 514.10mm
Depth (without stand)
48.40mm, 52.10mm, 53mm, 200mm
Display
Display resolution
1920 x 1080 pixels
Panel type
IPS, TFT, TN
Touchscreen
✗
Native aspect ratio
16:9, 4:3
Display technology
LCD, LED
Anti-glare screen
✓
Vertical scan range
[object Object],[object Object],[object Object],[object Object]
Contrast ratio (typical)
1000:1, 600:1
Horizontal scan range
[object Object],[object Object],[object Object],[object Object]
Display number of colours
16.7 million colours, 16.78 million colours
Pixel pitch
0.25 x 0.25, 0.25 x 0.25
Viewing angle, horizontal
90°, 170°, 178°
Viewing angle, vertical
65°, 160°, 178°
Contrast ratio (dynamic)
10000000:1, 80000000:1, 8000000:1, 50000000:1, 100000000:1
Dynamic contrast ratio marketing name
SmartContrast
Response time
1ms, 5ms
Power
Energy efficiency scale
A+++ to G
Power consumption (typical)
11.20W, 12W, 14.48W, 15.69W, 16W, 20.21W, 21.10W, 25W
AC input voltage
100 - 240 V
Energy consumption (SDR) per 1000 hours
10kWh, 11kWh, 13kWh, 16kWh, 19kWh
Energy efficiency class (HDR)
Not available
Energy efficiency class (SDR)
C, D, E, F
AC input frequency
50 - 60 Hz
Power consumption (max)
35 W
Power consumption (standby)
0.30W, 0.50W, 1W
Power consumption (off)
0.20W, 0.30W, 0.50W
Power consumption (PowerSave)
0.50W, 1W
Performance
On Screen Display (OSD) languages
Simplified Chinese, Traditional Chinese, German, Dutch, English, Spanish, French, Italian, Japanese, Korean, Russian
Low Blue Light technology
✓
On Screen Display (OSD)
✓
HDCP
✓
Game mode
✓
AMD FreeSync
✓
TV tuner integrated
✗
AMD FreeSync type
FreeSync
Flicker-free technology
✓
Other features
Heavy metals free
Hg (mercury)
Cable lock slot type
Kensington
Screen format adjustments
4:3
Ergonomics
Custom key function
✓
Design
VESA mounting
✓
LED indicators
Power, Stand-by, Yes
Cable lock slot
✓
Market positioning
Business, Gaming, Home
Panel mounting interface
100 x 100
Front bezel colour
Black
Pivot
✗
Screen shape
Flat
Swivelling
✗
Frameless design
✓
Height adjustment
✗
Graphics
NVIDIA G-SYNC
✗
Packaging content
Quick start guide
✓
Manual
✓
Cables included
AC, Audio (3.5mm), DVI, HDMI, HDMI-DVI, USB, VGA
Stand included
✓
AC adapter included
✓
Camera included
✓
Network
Wi-Fi
✗
Bluetooth
✗
Ethernet LAN
✗
Ports & interfaces
Headphone out
✓
Headphone outputs
1
Microphone in
✓
AC (power) in
✓
Headphone connectivity
3.5 mm
DVI-D ports quantity
1
VGA (D-Sub) ports quantity
1
Built-in USB hub
✗
USB hub version
2.0
HDMI version
1.4
PC Audio out
✓
HDMI
✓
PC in (D-Sub)
✓
PC Audio in
✓
HDMI ports quantity
1, 2
DVI port
✓
USB Type-A downstream ports quantity
1
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
10 - 80 %
Storage relative humidity (H-H)
5 - 90 %
Technical details
Certification
BSMI, C-Tick, CB, CCC, CEL 1, CEL level 1, CEL level 2, CU, China Energy Label Level 1, EK, Energy Star®, ErP, FCC, Gost-R, J-MOSS, MEPS, PSB, PSE, RCM, TCO6.0, TUV, TUV Flicker-free, TUV Low Blue Light, TUV-Ergo, TUV-GS, TÜV Flicker-free
TÜV Low Blue Light, UL/cUL, VCCI, WEEE, WHQL, WHQL (Windows 8.1, Windows 7, Windows 7), Windows 8.1
Sustainability certificates
ENERGY STAR, EPEAT Gold
Audio
Built-in speaker(s)
✓
Number of speakers
2
RMS rated power
2W, 3W, 4W
Video
HD type
Full HD
Supported video modes
1080p
Camera
Built-in camera
✓
Megapixel (approx.)
1 MP
Thin Client
Thin client installed
✗
Logistics data
Harmonized System (HS) code
85285210
Hospitality features
Hotel mode
✓
Pan-tilt unit
Tilt angle range
5 - 20 °
Product Details
1ms Quick Response Time Monitor
- 21.5” Full HD monitor with 1ms (GTG) quick response time to eliminate ghosting and tracers for more fluid video playback
- ASUS-exclusive GamePlus provides Crosshair and Timer function for better gaming experience
- The TÜV Rheinland-certified ASUS Flicker-Free and Low Blue Light technologies
- Extensive connectivity including DVI-D, and D-sub ports. Plus 1.5-Watt stereo speakers.
Superior Image Quality Meets Classic Elegant Design
VP228TE 21.5” Full HD monitor with 100,000,000:1 high contrast ratio, ASUS-exclusive SplendidPlus and VivdPixel technologies is optimized for the finest image and color quality. This approach extends to the study stand and slim profile without compromising style in ensuring stability and durability.
100,000,000:1 ASUS Smart Contrast Ratio
Dynamically enhances the display’s contrast by adjusting the luminance of the backlight to achieve the darkest black and brightest white – delivering lifelike images.
1ms Quick Response Time
1ms (GTG) quick response time eliminates ghosting and tracers for more fluid video playback.
ASUS-exclusive GamePlus Technology
When it comes to design, ASUS always have customers in mind – the ASUS VP228TE features the ASUS-exclusive GamePlus hotkey with crosshair and timer functions. Gamers can select four different crosshair types to suit the gaming environment; while the latter keeps players aware of the elapsed time in real-time strategy games. These tools allow gamers to practice and improve on their gaming skills.
ASUS-exclusive SplendidPlus Technologies
We’ve raised the bar by incorporating some of our proprietary technologies into the ASUS VP228TE to give you a truly vivid visual experience. The VP228TE features the new SplendidPlus™ Video Intelligence Technology that optimizes videos and images by enhancing color brightness, contrast, and sharpness. SplendidPlus™ features two new modes – Reading and Darkroom – in addition to the Scenery, Standard, Theater, sRGB, and Night View modes. Low-blue Light and Flicker-free technologies also reduce the strain on your eyes after long periods of use.
VividPixel Technology for Best Picture Quality
ASUS VividPixel Technology helps enhance image outlines and reduce noise bars for crystal-clear and detail-oriented viewing.
Protect Your Eyes with ASUS Eye Care Technology
The VP228TE has undergone stringent performance tests and is certified by TÜV Rheinland laboratories, a global provider of technical, safety, and certification services, to be flicker-free and to emit low blue light levels.
Flicker-free Technology
Say goodbye to tired, strained eyes. The VP228TE features the
TÜV Rheinland-certified ASUS Flicker-Free technology designed to reduce flicker for a comfortable viewing experience. This minimizes instances of eyestrain and other damaging effects when you spend long, countless hours in front of a display.
ASUS Blue Light Filter
The VP228TE also comes with the TÜV Rheinland-certified ASUS Blue Light Filter to protect you from harmful blue light; a new OSD menu lets you easily access and select four different filter settings onscreen.
Files
EU Energy Label
mmo_106151013_1674048378_127_18605.pdf
PDF• 64 KB
EU Product Fiche
mmo_106151013_1674048378_0702_30500.pdf
PDF• 69.4 KB
User manual
mmo_106151013_1674048378_8075_18194.pdf
PDF• 2.3 MB
