Acer XV340CK - 34" 3440 x 1440
Key Features
- VESA Adaptive Sync support: Yes
- USB upstream port type: USB Type-B
- DDC/CI: Yes
- Display brightness (typical): 250, 300, 320, 400, 550cd/m²
- Number of upstream ports: 1
- USB Type-A downstream ports quantity: 1, 2, 4, 5
- Thin client installed: No
- Flicker-free technology: Yes
- Detachable stand: Yes
- AMD FreeSync type: FreeSync Premium
- Picture-by-Picture (PbP): Yes
- Wall mountable: Yes
- Colour gamut standard: sRGB
- Aspect ratio: 21:9
- Resolution: 3440 x 1440pixels
Specifications
Features
Mean time between failures (MTBF)
30000 h
3D
✗
Feet colour
Black, Silver
Viewable size, vertical
333mm, 335mm
On/off switch
✓
Viewable size, horizontal
796mm, 800mm
Digital vertical frequency
[object Object],[object Object],[object Object],[object Object]
Digital horizontal frequency
[object Object],[object Object],[object Object]
Tilt adjustment
✓
Maximum refresh rate
50Hz, 75Hz, 100Hz, 144Hz, 180Hz
Product colour
Black, Silver
Audio input
No
Wall mountable
✓
Colour gamut standard
sRGB
Aspect ratio
21:9
Resolution
3440 x 1440 pixels
Display
LED
Brightness
300 cd/m²
Supported graphics resolutions
3440 x 1440
Backlight type
LED
Display brightness (typical)
250cd/m², 300cd/m², 320cd/m², 400cd/m², 550cd/m²
Packaging data
Package type
Box
Package weight
9100g, 12200g
Sustainability
European Product Registry for Energy Labelling (EPREL) code
401663
Weight & dimensions
Net weight
6550 g
Package weight
9.10kg, 12.20kg
Weight
6550 g
Weight (with stand)
8600g, 8900g, 9600g, 9700g, 9710g, 9800g
Height (with stand)
447mm, 523.50mm, 524mm, 565mm, 565.40mm, 565.50mm, 566.40mm, 597mm, 604mm
Depth (with stand)
246mm, 246.10mm, 269mm, 309mm, 309.10mm, 309.90mm
Width (with stand)
815mm, 815.30mm, 816mm, 816.10mm, 816.20mm, 817mm
Weight (without stand)
5600g, 6530g, 6550g, 6700g, 6760g, 6800g
Height (without stand)
360mm, 365.70mm, 367mm, 367.70mm, 367.80mm, 368mm, 368.30mm, 447mm
Width (without stand)
536.70mm, 815mm, 815.30mm, 816.20mm, 817mm
Depth (without stand)
58mm, 58.60mm, 121mm, 124.50mm, 124.70mm, 125mm
Display
Display resolution
3440 x 1440 pixels
Display diagonal (metric)
86.40 cm
Panel type
IPS
Touchscreen
✗
Native aspect ratio
21:9
Colour gamut
99 %
Display technology
LCD, LED
High Dynamic Range (HDR) technology
DisplayHDR 400, High Dynamic Range 10 (HDR10)
Anti-glare screen
✓
Vertical scan range
[object Object],[object Object]
Contrast ratio (typical)
1000:1
Horizontal scan range
[object Object],[object Object]
Display number of colours
1.073 billion colours, 16.7 million colours, 16.78 million colours
sRGB coverage (typical)
99%, 100%
Pixel pitch
9.20 x 9.20, 0.23 x 0.23, 0.23 x 0.23
Viewing angle, horizontal
172°, 178°
Viewing angle, vertical
178 °
Contrast ratio
100000000:1
Contrast ratio (dynamic)
100000000:1
LED backlight
✓
Pixel density
121 ppi
Response time
1ms, 5ms, 6ms
Colour depth
8 bit
DDC/CI
✓
Power
Energy efficiency class (old)
B, C
Energy efficiency scale
A+++ to G
Power consumption (typical)
36W, 50W, 51W, 52W, 53W, 53.60W, 56W, 57W, 65W
AC input voltage
100 - 240 V
Energy consumption (HDR) per 1000 hours
46kWh, 57kWh
Energy consumption (SDR) per 1000 hours
36kWh, 37kWh
Energy efficiency class (HDR)
G
Energy efficiency class (SDR)
G
AC input frequency
50 - 60 Hz
Power consumption (max)
80W, 90W
Power consumption (standby)
0.50 W
Power consumption (off)
0.30W, 0.40W, 0.45W, 0.48W, 0.50W
Power consumption (PowerSave)
51W, 52W
Annual energy consumption
78kWh, 83kWh, 88kWh, 92kWh
Power consumption (economy mode)
51 W
Performance
AMD FreeSync
✓
TV tuner integrated
✗
Picture-in-Picture
✓
AMD FreeSync type
FreeSync Premium
Flicker-free technology
✓
VESA Adaptive Sync support
✓
Other features
Set weight (with stand)
9700 g
Anti-Blue-Light technology
✓
Cable lock slot type
Kensington
Speakers
Y
Design
VESA mounting
✓
Mercury content
0 mg
Cable lock slot
✓
Market positioning
Gaming, Graphics design, Home
Panel mounting interface
100 x 100
Front bezel colour
Black
Pivot
✗
Screen shape
Flat
Swivelling
✓
Frameless design
✓
Height adjustment
✓
Detachable stand
✓
Graphics
NVIDIA G-SYNC
✗
Packaging content
Packaging content
XR342CK Widescreen LCD Monitor
1 x Displayport Cable
1 x HDMI Cable
Power Cord
1 x USB 3.0 Cable
Quick start guide
✓
Cables included
AC, DisplayPort, HDMI, USB, USB Type-C, USB Type-C to USB Type-C
Stand included
✓
AC adapter included
✓
Camera included
✗
Ports & interfaces
DC-in jack
✓
Headphone out
✓
Headphone outputs
1
DisplayPort version
1.2, 1.4
Built-in USB hub
✓
USB hub version
3.2 Gen 1 (3.1 Gen 1), 3.2 Gen 2 (3.1 Gen 2)
DisplayPorts quantity
1, 2
HDMI version
2.0
Mobile High-Definition Link (MHL)
✓
HDMI
✓
Audio output
Yes
Mini DisplayPorts quantity
1
HDMI ports quantity
1, 2
DVI port
✗
USB Type-A downstream ports quantity
1, 2, 4, 5
Number of upstream ports
1
USB upstream port type
USB Type-B
Operational conditions
Operating temperature (T-T)
5 - 35 °C
Operating relative humidity (H-H)
10 - 85 %
Technical details
Certification
CCC, CE, EAC, FCC, ISO9241-307 class I
MPRII, MPR II, NOM, RoHS, TÜV GS, VCCI
Sustainability certificates
ENERGY STAR
SmartResponse
1 ms
Picture-by-Picture (PbP)
✓
Audio
Audio system
DTS Sound
Built-in speaker(s)
✓
Number of speakers
2
RMS rated power
3W, 6W, 7W, 14W
Video
High Dynamic Range (HDR) supported
✓
HD type
4K Ultra HD, Quad HD, UltraWide Quad HD
Supported video modes
1440p
Camera
Built-in camera
✗
Thin Client
Thin client installed
✗
Logistics data
Harmonized System (HS) code
85285210
Product Details
Ascend into UltraWide Immersion
Never miss another second of the action. With up to 34” of glorious 3440x1440 (21:9) UltraWide QHD[1] resolutions to work and game with, completely immerse yourself into your games in ways you have never experienced before.
Silky Smooth Visuals
When the action gets intense, precision is key. With a rapid refresh rate of 144Hz[2], experience ultra-smooth viewing with faster frame rendering and lower input lag to make better decisions, faster.
No Screen Tearing
Make screen tears a thing of the past. With AMD FreeSync™ [3], frames are synced with the graphics card’s frames perfectly, delivering visually smooth gaming experiences.
Lifelike Images
Bring your gameplay to life. With HDR10 support allowing for expanded contrast ratio and color palette, you get deeper levels of black and white contrast to create even more realistic and natural images.
Give Yourself a Boost
Visual Response Boost™ [4] technology creates the effect of 1ms MPRT (Moving Picture Response Time), giving your screen less blur for crystal clear gameplay.
Eye Safety First
Get ready to settle in for those long gaming sessions. By utilizing Acer BlueLightShield™ and Flickerless™ technologies, protect your eyes from unnecessary strain and fatigue so you can do even more before you take a break.
Hyper-Reactive Gameplay
Edge out the competition with even quicker reaction times. With ultra-low input lag, shave off precious milliseconds to always beat your opponents to the punch.
[1] - Specifications may vary depending on model and/or region. All models subject to availability.
[2] - Actual refresh rates may vary depending on model and/or region, computer specifications/hardware and/or set up. This device is designed to support refresh rate overclocking. However, overclocking may result in system instability. If you experience instability, try reducing the overclock to a lower refresh rate through the on-screen display settings.
[3] - For Radeon™ FreeSync technology, users will require: a monitor compatible with DisplayPort Adaptive-Sync or HDMI, a compatible Radeon™ GPU with a DisplayPort or HDMI connection, and a compatible Radeon™ Software graphics driver.
[4] - Specifications may vary depending on model and/or region. 1ms VRB value based on internal tests under specific test conditions. Level of brightness may vary as a result of Visual Response Boost™ mode in use.
