Viewsonic VA2709U-4K - 27" 3840 X 2160
Key Features
- USB upstream port type: USB Type-C
- Response time (fast): 4ms
- Display brightness (typical): 350cd/m²
- Display brightness (peak): 360cd/m²
- Number of upstream ports: 2
- Number of USB Type-B upstream ports quantity: 1
- USB Type-A downstream ports quantity: 4
- USB Type-C downstream ports quantity: 1
- Number of USB Type-C upstream ports quantity: 1
- Flicker-free technology: Yes
- Detachable stand: Yes
- Wall mountable: Yes
- Colour gamut standard: Adobe RGB, DCI-P3, NTSC, sRGB
- Aspect ratio: 16:9
- Resolution: 3840 x 2160pixels
Specifications
Features
Country of origin
China
DCI-P3 coverage
98 %
Mean time between failures (MTBF)
30000 h
Plug and Play
✓
3D
✗
Feet colour
Black
Viewable size, vertical
335 mm
Viewable size, horizontal
597 mm
Digital vertical frequency
24 - 75 Hz
Digital horizontal frequency
15 - 204 kHz
Tilt adjustment
✓
Maximum refresh rate
60 Hz
Product colour
Black
Audio input
No, Yes
Wall mountable
✓
Colour gamut standard
Adobe RGB, DCI-P3, NTSC, sRGB
Aspect ratio
16:9
Resolution
3840 x 2160 pixels
Display
LCD
Supported graphics resolutions
3840 x 2160
Backlight type
LED, W-LED
Display brightness (peak)
360 cd/m²
Display brightness (typical)
350 cd/m²
Packaging data
Package type
Box
Package weight
13200 g
Package height
465 mm
Package depth
225 mm
Package width
740 mm
Sustainability
European Product Registry for Energy Labelling (EPREL) code
1255097
Weight & dimensions
Package weight
13.10 kg
Weight (with stand)
8300 g
Height (with stand)
546 mm
Depth (with stand)
215 mm
Width (with stand)
613 mm
Weight (without stand)
5100 g
Height (without stand)
363 mm
Width (without stand)
613 mm
Depth (without stand)
53 mm
Display
Adobe RGB coverage
100 %
Display resolution
3840 x 2160 pixels
Display diagonal (metric)
69 cm
Panel type
IPS
Touchscreen
✗
Native aspect ratio
16:9
Colour gamut
91 %
Display technology
LCD, LED
High Dynamic Range (HDR) technology
HDR 10+
Anti-glare screen
✓
Vertical scan range
24 - 120 Hz
Contrast ratio (typical)
1000:1
Horizontal scan range
15 - 130 kHz
Display number of colours
1.07 billion colours
NTSC coverage (typical)
91 %
sRGB coverage (typical)
100 %
Pixel pitch
0.15 x 0.15 mm
Viewing angle, horizontal
178 °
Viewing angle, vertical
178 °
Contrast ratio (dynamic)
20000000:1
Haze rate
25 %
LED backlight
✓
Response time
5 ms
Colour depth
10 bit
Surface hardness
3H
Response time (fast)
4 ms
Power
Energy efficiency class (old)
B
Power supply type
Internal
Energy efficiency scale
A+++ to G
Power consumption (typical)
42 W
AC input voltage
100 - 240 V
Energy consumption (HDR) per 1000 hours
61 kWh
Energy consumption (SDR) per 1000 hours
26 kWh
Energy efficiency class (HDR)
G
Energy efficiency class (SDR)
F
AC input frequency
50 - 60 Hz
Power consumption (max)
70 W
Power consumption (standby)
0.50 W
Power consumption (off)
0.30 W
Power consumption (PowerSave)
45 W
Annual energy consumption
60 kWh
Performance
Low Blue Light technology
✓
Number of OSD languages
14
On Screen Display (OSD)
✓
HDCP
✓
Game mode
✓
AMD FreeSync
✗
TV tuner integrated
✗
Flicker-free technology
✓
Other features
Cable lock slot type
Kensington
Separate H/V sync
✓
Composite sync
✓
Sync-on-green (SOG)
✓
Ergonomics
Cable management
✓
Design
VESA mounting
✓
LED indicators
Yes
Cable lock slot
✓
Market positioning
Graphics design
Panel mounting interface
100 x 100
Pivot angle
90 - 90 °
Front bezel colour
Black
Pivot
✓
Screen shape
Flat
Swivelling
✓
Frameless design
✓
Height adjustment
✓
Swivel angle range
0 - 120 °
Detachable stand
✓
Graphics
NVIDIA G-SYNC
✗
Packaging content
Quick start guide
✓
Manual
✓
Cables included
AC, DisplayPort, HDMI, MHL, Mini DisplayPort, Power, USB, USB Type-A to USB Type-B, USB Type-C
Stand included
✓
AC adapter included
✓
Camera included
✗
Power adapter included
✓
Network
Ethernet LAN
✓
Ports & interfaces
DC-in jack
✓
USB Power Delivery (USB PD)
✓
USB Type-C DisplayPort Alternate Mode
✓
Headphone out
✓
Headphone outputs
1
Headphone connectivity
3.5 mm
DisplayPort version
1.2a
Built-in USB hub
✓
USB hub version
3.2 Gen 1 (3.1 Gen 1)
DisplayPorts quantity
1
HDMI version
2.0, 2.1, 2.2
Thunderbolt 4 ports quantity
2
Mobile High-Definition Link (MHL)
✓
HDMI
✓
Audio output
Yes
Mini DisplayPorts quantity
1
HDMI ports quantity
2
USB Power Delivery up to
60 W
DVI port
✗
Number of USB Type-C upstream ports quantity
1
USB Type-C downstream ports quantity
1
USB Type-A downstream ports quantity
4
Number of USB Type-B upstream ports quantity
1
Number of upstream ports
2
USB upstream port type
USB Type-C
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
20 - 90 %
Technical details
Certification
CB, CE, ErP, FCC-B, Mexico CoC, REACH, RoHS, UL, WEEE, cUL
Sustainability certificates
ENERGY STAR, EPEAT Gold, ErP
Compliance certificates
CE, REACH, RoHS, WEEE
Audio
Built-in speaker(s)
✓
Number of speakers
2
Built-in subwoofer
✗
RMS rated power
2 W
Video
High Dynamic Range (HDR) supported
✓
HD type
4K Ultra HD
Supported video modes
1080p, 2160p
Camera
Built-in camera
✗
Logistics data
Harmonized System (HS) code
85285210
Pan-tilt unit
Tilt angle range
3 - 21 °
Product Details
OVERVIEW
Artists render fleeting moments of beauty by their vision. Now there’s a color monitor that delivers on printing that vision with unparalleled color adjustment and soft-proofing technology. With 100% Adobe RGB & 98% DCI-P3, True 10bit Color and Fogra and G7 Certification, the quality of your color is guaranteed. You may choose to broaden your palette with multiple suggestions, courtesy of ColorPro Sense. Or fine tune your vision with fingertip control using the ColorPro Wheel for calibration and adjustment. See it, dream it and print your vision. Beauty in the Mundane.
BEAUTY IN THE MUNDANE
Introducing the ColorPro VP86 Series
VP2786-4K
Artists render fleeting moments of beauty with their vision.
Eyes always scanning their environment, in search for inspiration. With 100% Adobe RGB,
True 10bit Color, Fogra, and G7 Certification, quality of colors and soft-proofing are guaranteed.
Verify your colors and broaden your palette with ColorPro Sense's Pantone integration.
See it, dream it and print it. Beauty in the Mundane.
Maximum Performance. Award-Winning Minimalist Design.
When it comes to beauty and performance, no detail was overlooked.
More Power for Your Palette
Photographers
100% Adobe RGB, and true 10-bit color technology delivers amazing accuracy. So your unedited RAW files can be quickly and easily fine-tuned for precision and perfectly printed outputs. Not to mention how our Portable Darkroom can help you eliminate ambient light when you need dark-room focus.
Printing professional
With Fogra & G7 certification, plus a Delta E < 2, the VP2786-4K delivers industry-leading printing quality and color fidelity for a soft-proofing process that delivers the truest representation of your work. Colors will be exceptional accurate and consistent on your final output, every time.
Photo & Video Coloristes
Our exclusive ColorPro Wheel puts easy access to Adobe software, on-screen displays and color calibration adjustments at your fingertips. Exclusive ColorPro Sense includes instant palette expansion for you to choose from Pantone colors and easily share your vision with everyone in your workflow.
The Power of Precision
About 35% larger than sRGB, 100% Adobe RGB puts a greater power of precision in your control. The larger range of color space empowers you to more accurately reproduce and fine tune your RAW files for perfect outputs. Whether for photography competitions, publishing, or soft-proofing a commercial advertising project, you won’t find a more serious color management tool to meet your most exacting requirements.
100% Adobe RGB 98% DCI-P3
Identical From Screen to Print
Recognition by Fogra as a Class A soft-proof monitor and G7 Method certification mean the VP2786-4K has been verified by the most credible global organizations in the printing industry. So any photograph or design you produce on it will achieve the absolute highest quality match between what is displayed on the monitor and the final printed piece – absolutely accurate and consistent with your vision.
Fogra Certified
G7 Idealliance Certified
Flawless Color Reproduction
Upgrading to an Adobe RGB color gamut without improving color depth standard can lead to uneven color transitions that may cause color gaps. So make sure you upgrade the color depth standard to 10-bit. A 10-bit panel, like the VP2786-4k can present up to 1.07 billion colors, with far more natural, smoother color transitions.
True 10 bit Color
The Details Don’t Lie
The High Dynamic Range of HDR10 combined means greater control over gamma adjustment for your video and photographic projects. Now you can bring out the subtle vibrance of light,and plumb the depth of your darks with enhanced clarity and unparalleled detail.
HDR 10
Fingertip Color Control
The World's First Professional Monitor With Fingertip Color Control
Sensitivity, balance and perfect alignment harmonize in the ColorPro Wheel interface. Instant color adjustments are just an intuitive click or spin away. You'll be amazed at how quickly it feels like an organic extension of your own hand.
ColorPro Wheel
Your Palette Power Maximize
The exclusive ColorPro Sense can deliver multiple alternate palette suggestions automatically. Just choose any grouping that matches your vision and easily share it with everyone in your workflow for more suggestions on creating your unique color story.
ColorPro Sense
Powered By Pantone
Supercharge Your Workflow with Intuitive Software Integration
Instant access to compatible Adobe Creative Suite or Capture One editing software and on-screen displays is simply a click & spin away with the Color Wheel. Zoom in and out, adjust brush size, brightness settings, opacity and more.
Color Calibration Has Never Been Easier
The ColorPro Wheel makes color calibration simple, fast, and accurate. By integrating the imbedded, lens-based color sensor with the Colorbration+ software, you can control your color with confidence. Software and Hardware combine to give you complete control over your workflow.
Quick, Easy Display Adjustments
No more fiddling with the bezel buttons! The ColorPro Wheel affords easy access to on-screen display parameters. Just click and turn to scroll and adjust brightness, contrast, and more.
Quick & Crystal Clear
Let There Be Light!
It's vital to see your workspace and the built-in Backstage Light™ light provides illumination during darkroom conditions. With white, warm white and yellow lights to choose from, you can change the lighting at will.
Instant Darkroom
The removable hood attaches magnetically to help eliminate ambient light for when you need dark room focus. And detaches in an instant.
Magnetic Hood
Files
User manual
mmo_115176457_1710496622_0429_23287.pdf
PDF• 1 MB
EU Energy Label
PNG• 335.6 KB
QSG
mmo_120223691_1729585417_8493_1199758.pdf
PDF• 38.7 MB
EU Product Fiche
mmo_120223691_1729585346_643_4126815.pdf
PDF• 109.3 KB
Product Brochure
mmo_120223691_1729585359_2851_4130717.pdf
PDF• 449 KB
Quick Start Guide
mmo_85735381_1634773215_0258_10308.pdf
PDF• 815.6 KB
Quick Guide
mmo_92300546_1632657117_0297_56764.pdf
PDF• 854.6 KB
Quick start guide
mmo_99942777_1655802351_0719_32559.pdf
PDF• 6.7 MB
