Hikvision DS-2CD2346G2P-ISU/SL

Name: Hikvision DS-2CD2346G2P-ISU/SL
Brand: Hikvision
SKU: 753218
Availability: InStock

Best offer

AED

699⁰⁰

Key Features

Camera tilt control: Yes
Auto patrol mode: Yes
Detect distance: 77m
Observe distance: 30m
Recognize distance: 7m
Camera pan control: Yes
Noise reduction technology: 3D noise reduction
Auto-tracking: Yes
Lens viewing angle, vertical: 55°°
Lens viewing angle, diagonal: 123°°
Power consumption (Power over Ethernet (PoE)): 8.8W
Identify distance: 7m
Infrared (IR) cut-off filter: Yes
User access level: User
Digital watermark: Yes

Specifications

Features

Web browser

✓

Protection features

Dust resistant, Water resistant, Waterproof

Voice codecs

AAC, G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, PCM

Weatherproof

✓

Number of sensors

Built-in microphone

✓

Audio formats supported

AAC-LC, G.711, G.722.1, G.726, MP2L2, MP3, PCM

Card reader integrated

✓

Quality of Service (QoS) support

✓

Maximum memory card size

256 GB

Password protection

✓

Video motion detection

✓

Security algorithms

EAP-LEAP, EAP-MD5, EAP-TLS, TLS

Languages support

Traditional Chinese, Danish, German, Dutch, Finnish, Hungarian, Italian, Japanese, Korean, LAT, Multi, Polish, Portuguese, RON, Russian, SER, Slovak, Slovenian, SPA, Swedish, Thai, Turkish, Vietnamese

Number of languages

Connectivity technology

Wired

Product colour

White

Video streaming

✓

Digital watermark

✓

Fixed focus

✓

Alert notification type

E-mail

Type

IP security camera

Active tampering alarm

✓

Mirror

✓

Audio codecs

G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC

Motion sensor

✓

Sample rate

48 kHz

Audio output channels

Supported graphics resolutions

1200 x 536, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2304 x 1296, 2592 x 1944, 2688 x 1520, 3040 x 1368, 360 x 240, 640 x 360, 640 x 480 (VGA)

Recognize distance (wide)

12 m

Detect distance

77 m

Packaging data

Package weight

1090 g

Package height

150 mm

Package depth

170 mm

Package width

170 mm

Weight & dimensions

Weight

800 g

Height

124.50 mm

Depth

306.50 mm

Width

118.60 mm

Diameter

138 mm

Length

287.60 mm

Management features

Web-based management

✓

Behavior analysis

Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection

Power

Power consumption (max)

10.50 W

DC output current

0.65 A

Power source type

DC output voltage

Power consumption (Power over Ethernet (PoE))

8.80 W

Performance

Auto-tracking

✓

Camera pan control

✓

Auto patrol mode

✓

Other features

I/O ports

1x line in, 1x line out

Noise reduction

✓

Ergonomics

Angle of rotation

360 °

Storage

Compatible memory cards

MicroSD (TransFlash), MicroSDHC, MicroSDXC

Built-in HDD

✗

Design

International Protection (IP) code

IP67

Housing material

Aluminium, Metal

Placement supported

Indoor/Outdoor, Outdoor

Reset button

✓

Mounting type

Ceiling/Wall, Wall

Form factor

Bullet

Built-in light

✓

Network

Client interoperability

Hik-Central, Hik-Connect, iVMS-4200

Wi-Fi

✗

Bluetooth

✗

Networking standards

IEEE 802.1x, IEEE 802.3af, IEEE 802.3at

Supported network protocols

802.1X, ARP, Bonjour, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, NTP, PPPoE, QoS, RTP, RTSP, SFTP, SMTP, SNMP, SRTP, SSL/TLS, TCP/IP, UDP, UPnP, WebSocket, WebSockets, Websocket, Websockets

Ethernet interface type

Fast Ethernet

Ethernet LAN

✓

Live view

✓

Number of simultaneous live view channels

6 channels

User access level

User

Ports & interfaces

Ethernet LAN (RJ-45) ports

Alarm input channels

Alarm output channels

Operational conditions

Operating relative humidity (H-H)

0 - 95 %

Storage relative humidity (H-H)

0 - 95 %

Technical details

Certification

2016), B), BIS (IS 13252(1):2010+A1:2013+A2:2015), BIS (IS 13252(Part 1): 2010+A1: 2013+A2: 2015), BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005, CB (IEC 60950-1: 2005 + Am 1: 2009 + Am 2: 2013, CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, CB: IEC 62368-1: 2014+A11, CE-EMC (EN 55032: 2015, CE-EMC: EN 55032: 2015, CE-LVD (EN 60950-1: 2005 + Am 1: 2009 + Am 2: 2013, CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, CE-LVD: EN 62368-1: 2014/A11: 2017, CE-LVD: EN 62368-1: 2014/A11: 2017 CE-RoHS: 2011/65/EU, CE-LVD: EN 62368-1: 2014/A11: 2017 CE-RoHS: 2011/65/EU, EN 50130-4: 2011 +A1: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 + A1: 2014), EN 50130-4: 2011 +A1: 2014, EN 50130-4: 2011 +A1: 2014), EN 61000-3-2: 2014, EN 61000-3-2:2019, EN 61000-3-3: 2013, EN 61000-3-3: 2013+A1:2019, FCC (47 CFR 15, FCC (47 CFR 15, FCC: 47 CFR Part 15, IC (ICES-003: 6, IC (ICES-003: Issue 6, IC: ICES-003: Issue 7, IC: ICES-003: Issue 7 UL: UL 62368-1, IC: ICES-003: Issue 7 UL: UL 62368-1, IEC 62368-1: 2014 ), IEC 62368-1:2014 ), KC (KN 32: 2015, KC: KN32: 2015, KN 35: 2015) UL (UL 60950-1), KN35: 2015 UL: UL 62368-1, LOA (IEC/EN 60950-1), LOA (IEC/EN 60950-1) CE-RoHS (2011/65/EU), LOA: IEC/EN 60950-1 CE-RoHS: 2011/65/EU, RCM (AS/NZS CISPR 32: 2015), RCM: AS/NZS CISPR 32: 2015, Reach ( (EC) No 1907/2006), Reach ((EC) No 1907/2006), Reach: Regulation (EC) No 1907/2006, Subpart B, WEEE (2012/19/EU), WEEE: 2012/19/EU

Remote viewing

✓

Anti-flicker

✓

Compliance certificates

RoHS

Audio

Built-in speaker(s)

✓

Lens system

Lens mount interface

M12

Maximum aperture number

1.40

Number of lenses

Fixed focal length

2.80 mm

Detect distance (wide)

60 m

Observe distance (wide)

23.80 m

Identify distance (wide)

6 m

Identify distance

7 m

Noise reduction technology

3D noise reduction

Recognize distance

7 m

Observe distance

30 m

Video

Video compression formats

H.264, H.265, M-JPEG

Video formats supported

H.264, H.265, M-JPEG

Frame rate

30 fps

Image quality adjustment

Brightness, Contrast, Saturation, Sharpness

Privacy masking

✓

Security

IP address filtering

✓

Audit log

✓

Heartbeat

✓

Password reset via email

✓

Pixel counter

✓

Flash log

✓

Automatic Network Replenishment (ANR)

✓

Digest authentication

✓

HTTPS encryption

✓

Camera

Day/night mode

✓

Gain control type

Auto

Back Light Compensation (BLC)

✓

Field of view (FOV) angle

180 °

Camera shutter speed

1/3 - 1/100000 s

Bit rate control

Constant Bit Rate (CBR)/Variable Bit Rate (VBR)

Region of Interest (ROI) encoding

✓

Total megapixels

4 MP

Number of cameras

Bit rate

32 Kbps - 8 Mbps

Signal-to-Noise Ratio (SNR)

52 dB

Sensor type

CMOS

Lens viewing angle, horizontal

103°

Progressive scan

✓

Wide Dynamic Range (WDR)

✓

Intelligent Video Surveillance (IVS) system features

Defocus, Face detection, Human detection, People counting, Scene change, Vehicle detection

Alarm input/output

✓

Highlight Compensation (HLC)

✓

Lens viewing angle, diagonal

123°

Lens viewing angle, vertical

55°

Camera tilt control

✓

Amplifier

Sample rates

8 - 48 kHz

Pan-tilt unit

Tilt angle range

0 - 75 °

Pan range

0 - 360 °

Image sensor

Maximum resolution

2688 x 1520 pixels

Dynamic range

120 dB

Minimum illumination

0 lx

Infrared (IR) cut-off filter

✓

Night vision

✓

LED type

Night vision distance

30 m

Infra-red wavelength

850 nm

Product Details

Empowered by deep learning algorithms, Hikvision AcuSense technology brings human and vehicle targets classification alarms to front- and back-end devices. The system focuses on human and vehicle targets, vastly improving alarm efficiency and effectiveness.

Search targets quickly by type

Video clips are sorted by human and vehicle categories, and object classification vastly improves search efficiency.

Deep learning algorithm

The magic behind it all As its name implies, Hikvision AcuSense Technology provides accurate sensing in security hardware. Empowered by deep learning algorithms, AcuSense technology distinguishes people and vehicles from other moving targets.

Human and vehicle intrusion

Spotlights the events that matter The most common concerns in perimeter protection are trespassing and vehicle break-ins. AcuSense helps you to focus on these events in two ways: alarm will only trigger when the preset intrusion type takes place, and related videos are sorted by categories for easier search.

Accurate alarm for human and vehicle

You can focus on alarms triggered by humans and vehicles while false alarms triggered by small animals or other irrelevant objects are vastly reduced. Now you can enjoy this intelligent function with VCA or motion detection.

Visual and auditory warning

On-site response and deterrence methods using visual and customizable auditory warnings to add another layer of protection. Two-way audio function is now also available.

Files

Product Brochure

mmo_101929864_1663824373_6756_4622.pdf

PDF• 1 MB

Quick Start Guide

mmo_101929864_1663824387_0922_4539.pdf

PDF• 2.6 MB

User manual

mmo_101929864_1663824394_475_7484.pdf

PDF• 11.3 MB

Images

Videos

AcuSense products for Warehouses

MP4• 5.3 MB

AcuSense Products for Restricted Areas

MP4• 4 MB

AcuSense Products for Monitoring Centers

MP4• 7.5 MB

AcuSense Products for Residences

MP4• 8 MB
