Fitment: For Prado 150 2012 2014
Feature:
1. Condition: WithSO-N-Y lens, six-layer lens,100% new products and high quality.
2. hard-resistant function, strong blowing
3. Easy installation and simple operation
4. High definition camera reading, high definition and wide viewing angles
5. Ensure safe driving to avoid accidents on vehicles
6.Stable performance, low power consumption, low noise,HD camera, adjustment, night vision effect
Main Specification:
Operating temperature: -20 ° C ~ 70 °
Video Color: Color
Lens materials: 100% Glass
Optical format: Aptina MT9V136
Typical type: High-sensitivity mode for low-light conditions (Night Vision)
Degree of protection: IP67 (Waterproof)
System format: NTSC (Default), PAL(optional, please leave message to us if you need, free cost)
Power supply: 6V/12/24VDC Wide Input
Field view angle: 170degree (Diagonal), 138degree (Horizontal), 125 degree(Vertical) (more information from Option 2)
Optical distortion: -88% (more information from Option 2)
Horizontal resolution: 520TV lines (Pixels)
Output: RGB 720H x 480V@NTSC, 720H x 582V@PAL
Parking line: Manual Parking Line ON/OFF
Image: Manual Switch Mirror & Normal Image
Working time Continuous working
Operation temperature: -40°C to +80°C (-40°F to 176°F)
Package Retail: gift box (available for camera size smaller than 15cm/5.9inch)
Note: Default order : NTSC version/system, If you want to order PAL version, please leave us message before order. This service is free, But it may need 2-4 working days for preparing.
Freight bill:
1 * front view
1 * 6m video cable
1 * power cable
1 * user manual
red line, positive pole, connected to + 12V
(safe box / ACC / lighter position is OK)
black wire negative / ground
video plug, plug in the video input port of the display screen
digital rotary block, never heating, changing 12V voltage to 3.3V
1. After the installation of the central control navigation screen, Androld large screen,the car screen plus the function module protocol decoding box, in additionto the video input port used after reversing, there Is also reserved video input portdirectly before the installation Vision
2. If the central control navigation screen, Androld large screen and vehicle screen are equipped with function moduleprotocol decoding box, there Is only one way of reversing rear AUX Input port, which Is equipped withfront AUX camera, and two ways of video control box are needed
Captures Clear Front View: This car front camera dash cam records high-quality footage of the road ahead It provides clear images for safety monitoring, accident documentation, and driving assistance
Enhances Driving Security: The vehicle front view surveillance camera helps monitor traffic conditions and captures important incidents It improves situational awareness and protects against disputes or claims
Easy Direct Installation: This auto dash camera front unit mounts securely onto the windshield or dashboard It allows quick setup without complex wiring, making it convenient for immediate use
Durable and Reliable: The replacement front car video camera is built to withstand vibration, heat, and daily driving conditions It maintains consistent recording performance over time, ensuring dependable front-view monitoring
