For an ultra-fast home network
Spectacular wireless speed and a far greater range thanks to the new ultra-fast WiFi AC standard. Discover a model with exceptional qualities for Internet, telephony and multimedia applications.
Internet for all line types
Whether you have a DSL or VDSL line, the FRITZ!Box 7490 provides high-speed access within your home network. With state-of-the-art equipment, AC wireless standard, and Gigabit LAN and USB 3.0 technologies, you get incredibly fast connections and smooth navigation, without charging delays.
Wireless access to a new dimension
The new WiFi AC wireless standard has a significantly expanded range, with a throughput three times faster than previous standards. The use of two frequency bands makes it possible to integrate all your equipment in the best possible way – from tablet to laptop to smartphone, all your devices are connected at maximum speed.
Comfortable telephony
All your phones can be connected to FRITZ!Box 7490. And while you're on the go, you also stay informed of calls and voice messages you receive. Finally, answering machines and a fax function complete the whole thing.
The ultimate in entertainment every moment
The FRITZ!Box 7490 offers you outstanding technical entertainment anywhere in your home network. High-performance USB-3.0 ports make FRITZ!Box the perfect multimedia hub – your music, pictures and movies are available right away from anywhere. Now you have access to HD TV and your favorite music whenever you want.
Safely with FRITZ!Box
By choosing FRITZ!Box, you opt for safety! Very complete, its security system protects your communications. Tested and perfected by our teams, it is subject to regular and free updates that keep you safe from any danger.
FRITZ!OS – a system full of resources
FRITZ!OS, the operating system of your FRITZ!Box, regularly puts new features at your disposal. Thanks to the FRITZ!App apps, you can use your smartphone to access your data on the go, make phone calls within your home network or control your playback devices. Naturally, all updates and apps are free.
Simplicity praised by professionals and the general public
Welcomed by both the specialist press and consumers, the FRITZ!Box concept has one and only purpose – to make your life as easy as possible. So you have a clear user interface at your disposal, as well as wizards that accompany you step by step.
Other features:
3G: Yes
Security algorithms: TKIP,WEP,WPA-TKIP,WPA2,WPA2-AES,WPA2-CCMP
Removable antenna(s): no.
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz).
Frequency band: 2.4 & 5
Bandwidth (first): 5 GHz
Bandwidth (second): 2.4 GHz
Reset button: No
Mobile network connection: Yes
xDSL connection: Yes
Power consumption (typical): 9.3 W
Product colour: Red,Silver
Cables included: LAN (RJ-45)
DSL WAN: Yes
WLAN data transfer rate (max): 1300 Mbit/s
Downstream data rate: 100 Mbit/s
Ethernet/LAN: Yes
MAC Address Filtering: Yes
AC input frequency: 50 Hz
Web-based management: Yes
Rack mounting: Yes
Quick Start Guide: Yes
Height: 55 mm
Package height: 70 mm
Intel® inside: Yes
Ethernet LAN data rates: 1000 Mbit/s
Width: 245 mm
Package width: 307 mm
User Manual: Yes
Scalable Firmware: Yes
Internal modem: Yes
Number of Ethernet LAN (RJ-45) ports: 4
Number of USB ports: 2
Wi-Fi standard: Wi-Fi 5 (802.11ac)
3G standards: HSPA,UMTS
Firewall: Yes
Plug and play: yes.
Weight: 490 g
Package weight: 1.05 kg
Depth: 175 mm
Package depth: 240 mm
Antenna quantity: 6
RJ-11 ports quantity: 2
Automatic recognition of computer components: Yes
DHCP Server: Yes
Networking standards: IEEE 802.11ac
Wi-Fi standards: IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n.
Cabling technology: 10/100/1000Base-T(X)
AC input voltage: 200-230V
Antenna type: Internal
Ethernet LAN interface type: Gigabit Ethernet
VDSL: Yes
USB version: 3.0 (3.1 Gen 1).
WLAN data transfer rates: 450,1300 Mbit/s
LED indicators: DSL,Power,WLAN
