Synology RS1619xs+ 4-bay
Best offer
AED
7 29000
Key Features
- Storage drives installed: Yes
- Number of M.2 (M & B) slots: 2
- Total installed storage capacity: 16TB
- Power consumption (HDD standby): 34.78W
- Online RAID migration: Yes
- Online RAID expansion: Yes
- Power supply unit (PSU) capacity: 150W
- Device class: Small & Medium Business
- Backup features: Cloud, iSCSI LUN
- Number of storage drives installed: 4
- Installed storage drive type: HDD
- Processor threads: 4
- Storage drive size: 2.5/3.5"
- Hot-swap drive bays: Yes
- Multilingual support: Yes
Specifications
Features
ECC supported by processor
✓
Operating system installed
DiskStation Manager
Backup function
✓
Fan diameter
40 mm
On/off switch
✓
Security algorithms
HTTPS, SSH, SSL/TLS
Noise level
39.30 dB
CPU configuration (max)
1
Product colour
Black
Type
NAS
Access Control List (ACL)
✓
PCI Express slots version
2.0, 3.0
S.M.A.R.T. support
✓
Thermal Design Power (TDP)
35 W
Multilingual support
✓
Storage drive size
2.5/3.5
Installed storage drive type
HDD
Weight & dimensions
Weight
4340 g
Height
44 mm
Depth
518.60 mm
Width
480 mm
Management features
Web-based management
✓
Power
Power consumption (typical)
68.68 W
AC input voltage
100 - 240 V
Power supply location
Built-in
AC input frequency
50 - 60 Hz
Number of power supply units
2
Redundant power supply (RPS) support
✓
Power supply unit (PSU) capacity
150 W
Power consumption (HDD standby)
34.78 W
Performance
Processor ARK ID
91195
Processor operating modes
64-bit
Storage drive interface
M.2, Serial ATA, Serial ATA II, Serial ATA III
System log
✓
Hot spare
✓
Share folder
SMB/AFP/FTP
Number of storage drives installed
4
Backup features
Cloud, iSCSI LUN
Total installed storage capacity
16 TB
System requirements
Mac operating systems supported
Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave
Windows operating systems supported
Windows 10, Windows 7
Server operating systems supported
Windows Server 2016
Other features
RAID controller type
Yes
Browser supported
Chrome, Edge, Firefox, Internet Explorer 10+, Safari, Safari 10+
Chassis type
Rack (1U)
Digital Living Network Alliance (DLNA) certified
✓
Processor special features
Embedded options available
✓
Enhanced Intel SpeedStep Technology
✓
Execute Disable Bit
✓
Idle States
✓
Intel 64
✓
Intel Enhanced Halt State
✓
Intel Secure Key Technology version
1.00
Intel Trusted Execution Technology
✓
Intel TSX-NI
✓
Intel TSX-NI version
1.00
Intel Virtualization Technology (VT-x)
✓
Intel Virtualization Technology for Directed I/O (VT-d)
✓
Intel VT-x with Extended Page Tables (EPT)
✓
Intel® AES New Instructions (Intel® AES-NI)
✓
Intel® Hyper Threading Technology (Intel® HT Technology)
✓
Intel® OS Guard
✓
Intel® Secure Key
✓
Intel® Turbo Boost Technology
2.0
Maximum number of PCI Express lanes
32
Thermal Monitoring Technologies
✓
UART
✓
Memory channels supported by processor
Dual
Memory types supported by processor
DDR3-SDRAM, DDR4-SDRAM
Processor package size
37.5 x 37.5 mm
Processor code
SR2DK
Scalability
1S
Storage
HDD speed
7200
Supported file systems
BTRFS, FAT, HFS, NTFS, exFAT, ext3, ext4
RAID levels
0, 1, 1+0, 5, 6, F1, JBOD
RAID support
✓
Maximum supported storage capacity
56 TB
Supported storage drive types
HDD & SSD
Storage drive capacity
4000 GB
Number of storage drives supported
4
Storage drive sizes supported
2.5, 3.5
Supported storage drive interfaces
Serial ATA, Serial ATA II, Serial ATA III
Hot-swap drive bays
✓
Online RAID expansion
✓
Online RAID migration
✓
Number of M.2 (M & B) slots
2
Storage drives installed
✓
Design
Reset button
✓
LED indicators
Alarm, HDD, Power, Status, Yes
Cooling type
Active
Device class
Small & Medium Business
Computer system
Processor cores
4
Processor model
D-1527
Processor manufacturer
Intel
Processor frequency
2.20 GHz
Processor family
Intel® Xeon® D
Internal memory
8 GB
Packaging content
Cables included
AC
Quick installation guide
✓
Power cables quantity
2
Network
Wi-Fi
✗
Supported network protocols
AFP, CIFS, CalDAV, FTP, Fibre Channel, HTTP, HTTPs, L2TP), LDAP, NFS, NFS Kerberized sessions, NFSv3, NFSv4, NFSv4.1, OpenVPN, SMB1 (CIFS), SMB2, SMB3, SNMP, SSH, Telnet, VPN (PPTP, WebDAV, iSCSI
Ethernet LAN data rates
10, 100
Built-in FTP server
✓
Ethernet LAN
✓
iSCSI support
✓
Link aggregation
✓
Wake-on-LAN ready
✓
Ports & interfaces
Ethernet LAN (RJ-45) ports
4
Serial ports quantity
1
PCI Express configurations
1x16, 1x4, 1x8
USB port
✓
Expansion ports quantity
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
Concurrent connections
2000
Operational conditions
Operating temperature (T-T)
5 - 35 °C
Operating relative humidity (H-H)
5 - 95 %
Operating altitude
0 - 5000 m
Storage relative humidity (H-H)
5 - 95 %
Technical details
Sustainability compliance
✓
Certification
BSMI, CCC, CE, EAC, FCC, KC, RCM, VCCI
Compliance certificates
BSMI, CCC, CE, EAC, Federal Communications Commission (FCC), KC, RCM, RoHS, VCCI
Processor
Conflict-Free processor
✓
Maximum internal memory supported by processor
128 GB
Processor codename
Broadwell
Processor series
Intel Xeon D-1500
On-board graphics card model
Not available
Stepping
V2
Processor lithography
14 nm
Processor cache type
L3
Number of processors supported
1
L2 cache
6 MB
Processor socket
BGA 1667
Processor cache
6 MB
Processor boost frequency
2.70 GHz
Processor threads
4
Memory
ECC
✓
Memory form factor
UDIMM
Internal memory type
DDR4
Maximum RAM supported
64 GB
Memory slots
4
Camera
Snapshot
✓
Expansion slots
PCI Express x8 (Gen 3.x) slots
1
Logistics data
Harmonized System (HS) code
84714100
Product Details
Fast storage with outstanding computing power
RS1619xs+ is a high-performance and scalable 1U rackmount NAS designed with upgradable memory and M.2 SSD cache configuration to meet the needs of modern businesses that require a flexible, reliable, and efficient storage solution.
Variable options to boost system computing performance
Equipped with a PCIe 3.0 slot, RS1619xs+ supports installing a 10GbE/25GbE NIC for fast data transmission. Built-in M.2 2280 SSD cache slots further benefit IO-intensive tasks, such as virtualization or mail server deployment.
M.2 SSD support
Dual M.2 2280 slots supporting NVMe/SATA SSDs
10GbE/25GbE support
optional high-speed network capacity for bandwidth-intensive environments
Complete iSCSI and virtualization solutions
Synology iSCSI storage supports most virtualization solutions such as VMware vSphere, Microsoft Hyper-V, Citrix Xen Server, and OpenStack Cinder to enhance work efficiency. You can run and manage multiple virtual machines on Windows, Linux, or DSM using Virtual Machine Manager.
Next-generation file system for better data protection
The Btrfs file system introduces advanced storage technologies and optimized snapshots to prevent data corruption and reduce maintenance overhead. While ensuring high-level data integrity, it also offers flexible, efficient data protection and recovery tools.
- Flexible Shared Folder/User Quota System provides comprehensive quota control on all user accounts and shared folders
- Snapshot Replication provides schedulable and storage capacity-saving data protection with 1,024 shared folder backups and 65,000 system-wide snapshots
- File or folder level data restoration makes data recovery fast and flexible
- Automatic file self-healing detects and recovers corrupted files without user intervention
Ultimate Backup Solution
RS1619xs+ integrates various backup applications into an intuitive user interface, offering durable storage technologies to safeguard your valuable data on any device.
Active Backup for Business
Centralize backup tasks for VMware, Windows, and file servers. Restore whatever you want fast and reliably when needed.
Hyper Backup
Comprehensively back up your data to a local shared folder, an external device, another Synology NAS, an rsync server, or a public cloud to ensure data safety.
Drive Package
Safeguard your computer with Synology Drive Client. Effortlessly perform real-time data backups and point-in-time file recovery.
Active Backup for Microsoft 365 / G Suite
Protect corporate data stored on the cloud. On-premise backup solution with a centralized dashboard. Optimize storage efficiency with single instancing and block-level deduplication technology.
Digital asset protection
Powered by Synology DiskStation Manager (DSM), Synology NAS offers advanced security measures to protect against sudden data loss and potential security holes.
Security Advisor
Analyze system settings, password strength and network preferences, and remove any possible malware.
AppArmor
A kernel-level enhancement that blocks malicious programs from accessing unauthorized system resources.
AES 256-bit encryption
Encrypt shared folders and network data transmission to avoid unauthorized data access.
2-step verification
Prevent others from logging in to your DSM by generating a six-digit one-time password (OTP) on your mobile device.
Powered by Synology DSM
DSM UI
Award-winning operating system with an intuitive user interface and powerful capabilities.
Public Cloud Integration
Backup and synchronize data easily between your public cloud accounts and your NAS.
Synology High Availability
Seamless transition between clustered servers in the event of a server failure to minimize the impact on applications.
Snapshot Replication
Schedulable and instantaneous data protection of shared folders and iSCSI LUNs for quick disaster recovery.
Virtual Machine Manager
Run various operating systems in isolated sandboxes. Seamlessly clone, restore and migrate virtual machines.
Security
Comprehensive built-in security tools are constantly updated to protect your devices against evolving threats.
Files
Product Brochure
mmo_101257076_1714378232_5775_2924826.pdf
PDF• 599.5 KB
User manual
mmo_101257076_1714378233_3751_2924826.pdf
PDF• 7.3 MB
