Fitment: For RX RX270 RX350 RX450h AL10 2010 2012 2013~2015
Feature:
1. Condition: WithSO-N-Y lens, six-layer lens,100% new products and high quality.
2. hard-resistant function, strong blowing
3. Easy installation and simple operation
4. High definition camera reading, high definition and wide viewing angles
5. Ensure safe driving to avoid accidents on vehicles
6.Stable performance, low power consumption, low noise,HD camera, adjustment, night vision effect
Main Specification:
Operating temperature: -20 ° C ~ 70 °
Video Color: Color
Lens materials: 100% Glass
Optical format: Aptina MT9V136
Typical type: High-sensitivity mode for low-light conditions (Night Vision)
Degree of protection: IP67 (Waterproof)
System format: NTSC (Default), PAL(optional, please leave message to us if you need, free cost)
Power supply: 6V/12/24VDC Wide Input
Field view angle: 170degree (Diagonal), 138degree (Horizontal), 125 degree(Vertical) (more information from Option 2)
Optical distortion: -88% (more information from Option 2)
Horizontal resolution: 520TV lines (Pixels)
Output: RGB 720H x 480V@NTSC, 720H x 582V@PAL
Parking line: Manual Parking Line ON/OFF
Image: Manual Switch Mirror & Normal Image
Working time Continuous working
Operation temperature: -40°C to +80°C (-40°F to 176°F)
Package Retail: gift box (available for camera size smaller than 15cm/5.9inch)
Note: Default order : NTSC version/system, If you want to order PAL version, please leave us message before order. This service is free, But it may need 2-4 working days for preparing.
Freight bill:
1 * front view
1 * 6m video cable
1 * power cable
1 * user manual
red line, positive pole, connected to + 12V
(safe box / ACC / lighter position is OK)
black wire negative / ground
video plug, plug in the video input port of the display screen
digital rotary block, never heating, changing 12V voltage to 3.3V
1. After the installation of the central control navigation screen, Androld large screen,the car screen plus the function module protocol decoding box, in additionto the video input port used after reversing, there Is also reserved video input portdirectly before the installation Vision
2. If the central control navigation screen, Androld large screen and vehicle screen are equipped with function moduleprotocol decoding box, there Is only one way of reversing rear AUX Input port, which Is equipped withfront AUX camera, and two ways of video control box are needed
Enhances Front Visibility: This front car view camera improves your ability to see obstacles and road conditions directly ahead of your vehicle. Whether parking or driving in tight spaces, it helps reduce blind spots and enhances overall safety awareness
Reliable Visual Support: Designed for stable performance, the vehicle front camera lens provides a clear image feed to your screen or monitor. It supports real-time video input, helping you make more confident decisions in low-visibility or crowded environments
Discreet and Clean Fit: With a compact form factor, this car safety parking camera integrates neatly into your vehicle’s front exterior. It offers essential visibility without disrupting the design or drawing unnecessary attention to the installation point
Quick Installation Setup: This dashboard video input unit can be installed with minimal effort. Once connected, it begins providing visual data instantly—helping restore or upgrade your vehicle’s front monitoring capability in just minutes
