Intel 760P Series - 2.048TB M.2

Key Features

Component for: Server/workstation
SSD temperature monitoring: No
End-to-End Data Protection: Yes
Enhanced Power Loss Data Protection technology: No
Power consumption (idle): 0.025W
Uncorrectable Bit Error Rate (UBER): < 1 per 10^15 bits read
Power consumption (read): 0.07W
Power consumption (write): 0.07W
PCI Express interface data lanes: x4
NVMe: Yes
SSD capacity: 2050GB
SSD form factor: M.2
Hardware encryption: Yes
Memory type: 3D2 TLC
Intel High Endurance Technology (HET): No

Specifications

Features

Launch date

Q1'18

Temperature monitoring and logging

✗

Mean time between failures (MTBF)

1600000 h

Market segment

Mobile

Security algorithms

256-bit AES

Power consumption (idle)

0.03 W

Uncorrectable Bit Error Rate (UBER)

< 1 per 10^15 bits read

SSD temperature monitoring

✗

Component for

Server/workstation

Weight & dimensions

Weight

10 g

Depth

80 mm

Width

22 mm

Power

Power consumption (read)

0.07 W

Power consumption (write)

0.07 W

Performance

Maximum operating temperature

70 °C

Minimum operating temperature

0 °C

Other features

Random read (8GB span)

340000 IOPS

Random write (8GB span)

275000 IOPS

SSD power consumption (idle)

25 mW

Sequential writing speed

1625 MB/s

Sequential reading

3230 MB/s

SSD ARK ID

134581

TBW rating

576

Intel High Endurance Technology (HET)

✗

PCI Express interface data lanes

Processor special features

Intel® Rapid Start Technology

✓

Intel® Smart Response Technology

✓

Storage

NVMe

✓

SSD capacity

2050 GB

SSD form factor

M.2

Ports & interfaces

Interface

PCI Express 3.1

Operational conditions

Operating / non-operating shock

1000 G

Operating temperature (T-T)

0 - 70 °C

Non-operating vibration

3.13 G

Operating vibration

2.17 G

Non-operating shock

1000 G

Operating shock

1000 G

Technical details

Product codename

Harris Harbor

Status

Launched

Security

Hardware encryption

✓

Enhanced Power Loss Data Protection technology

✗

End-to-End Data Protection

✓

Brand-specific features

Intel® Remote Secure Erase

✗

Logistics data

Harmonized System (HS) code

84717070

Solid state drive

Memory type

3D2 TLC

Product Details

Intel® Smart Response Technology Intel® Smart Response Technology combines the fast performance of a small solid state drive with the large capacity of a hard disk drive. Hardware Encryption Hardware encryption is data encryption done at the drive level. This is used to ensure that the data stored on the drive is secured from unwanted intrusion. End-to-End Data Protection End-to-End Data Protection ensures integrity of stored data from the computer to the SSD and back. Intel® Rapid Start Technology Intel® Rapid Start Technology allows quick system resumes from the hibernate state.

High Performance

Accelerate your PC with PCIe* bandwidth, 64-layer Intel® 3D NAND Technology, twice the capacity, and twice the performance of its previous generation – the Intel® SSD 600p Series.

Low Power Consumption

Compared with its previous generation, the Intel® SSD 760p Series reduces its active power up to 50%.

Intel Quality and Reliability

Thanks to Intel’s industry leading quality and reliability, the Intel® SSD 760p Series supports AES 256-bit self-encryption and offers a 5-year limited warranty.

Made for Easy Installation

A small M.2 (80mm) form factor offers a wide range of capacities and simply plugs into M.2 - M key slots on major motherboards.

Files

Product Brochure

mmo_41554903_1519739263_4304_14151.pdf

PDF• 773 KB
