SSDSC2BB480G701 - 480GB 2.5-inch
SSDSC2BB480G701 - 480GB 2.5-inch
SSDSC2BB480G701 - 480GB 2.5-inch
SSDSC2BB480G701 - 480GB 2.5-inch
SSDSC2BB480G701 - 480GB 2.5-inch
SSDSC2BB480G701 - 480GB 2.5-inch
SSDSC2BB480G701 - 480GB 2.5-inch
SSDSC2BB480G701 - 480GB 2.5-inch
SSDSC2BB480G701 - 480GB 2.5-inch
SSDSC2BB480G701 - 480GB 2.5-inch
SSDSC2BB480G701 - 480GB 2.5-inch

Intel SSDSC2BB480G701 - 480GB 2.5-inch

Best offer
AED
1 52573

Key Features

  • NAND flash type: TLC (Triple Level Cell)
  • Random read (4KB): 48000IOPS
  • Random write (4KB): 30000IOPS
  • Random read (8KB): 48000IOPS
  • Random write (8KB): 85000IOPS
  • Random read (100% span): 96000IOPS
  • Random write (100% span): 44500IOPS
  • Write latency: 37µs
  • Read latency: 50µs
  • Component for: Server/workstation
  • SSD temperature monitoring: Yes
  • End-to-End Data Protection: Yes
  • Enhanced Power Loss Data Protection technology: Yes
  • Sequential latency - read (up to): 36µs
  • Sequential latency - write (up to): 36µs
  • Offers
  • Price History
  • Specifications
  • Product Details
  • Review IconReviews

Specifications

Features

Product series
Intel® SSD D3-S4610 Series
Launch date
Q3'18
Temperature monitoring and logging
✗
Mean time between failures (MTBF)
2000000 h
Market segment
Mobile
Security algorithms
256-bit AES
Native Command Queuing (NCQ)
✓
Lithography
20 nm
Product colour
Silver
Uncorrectable Bit Error Rate (UBER)
< 1 per 10^17 bits read
Data transfer rate
6 Gbit/s
S.M.A.R.T. support
✓
Power consumption (idle)
1 W
Random latency - write (up to)
43 µs
Random latency - read (up to)
103 µs
Sequential latency - write (up to)
36 µs
Sequential latency - read (up to)
36 µs
SSD temperature monitoring
✓
Component for
Server/workstation
NAND flash type
TLC (Triple Level Cell)

Weight & dimensions

Weight
78 g
Height
7 mm
Depth
100.50 mm
Width
69.80 mm

Power

Operating voltage
5 V
Power consumption (read)
0.17 W
Power consumption (write)
2.90 W
Power consumption (sleep)
0.01 W

Performance

Maximum operating temperature
70 °C
Minimum operating temperature
0 °C

Other features

Product family
Data center SSD
Power consumption (active)
3.10 W
Remote Secure Erase (RSE) technology version
0.00
Sequential writing speed
490 MB/s
Sequential reading
560 MB/s
SSD weight
72 g
SSD hardware encryption
AES 256 bit
SSD power consumption (active)
3.1W
SSD power consumption (idle)
1.0W
SSD endurance rating
3.0 PBW
Product brief URL
http://www.intel.com/content/www/us/en/solid-state-drives/ssd-pro-1500-series-brief.html
SSD shock
1
Random read (8GB span)
48000 IOPS
Random write (8GB span)
85000 IOPS
Drive capacity
480 GB
Intel Rapid Start Technology version
1
SSD ARK ID
134919
SSD usage tag
Consumer, Data center, Professional
TBW rating
275
Intel High Endurance Technology (HET)
✗

Processor special features

Intel Smart Response Technology version
1.00
Intel® Rapid Start Technology
✓
Intel® Smart Response Technology
✓

Storage

HDD capacity
480 GB
RAID support
✓
NVMe
✗
SSD capacity
480 GB
SSD form factor
2.5"

Design

Internal
✓

Computer system

Processor family
Intel SSD D3

Ports & interfaces

Interface
Serial ATA III

Operational conditions

Operating / non-operating shock
1000 G/0.5 msec
Operating temperature (T-T)
0 - 70 °C
Operating relative humidity (H-H)
5 - 95 %
Non-operating vibration
3.13 G
Operating vibration
2.17 G
Non-operating shock
1000 G
Operating shock
1000 G
Storage relative humidity (H-H)
5 - 95 %

Technical details

Product codename
Youngsville Refresh
Last change
63903513
Status
Discontinued
Product name
MLC)
Born on date
Q3'13
Commodity Classification Automated Tracking System (CCATS)
G162706
Certification
BSMI, CE, KCC, Microsoft WHCK/WHLK, RCM, SATA-IO, UL, VCCI
Compliance certificates
RoHS

Processor

Processor lithography
20 nm

Memory

ECC
✓
Internal memory type
SATA 3.0 6Gb/S

Security

TRIM support
✓
Hardware encryption
✓
Enhanced Power Loss Data Protection technology
✓
End-to-End Data Protection
✓

Brand-specific features

Intel® Remote Secure Erase
✓

Logistics data

Export Control Classification Number (ECCN)
5A992C
Harmonized System (HS) code
84717070

Solid state drive

Access time
500 ms
Read speed
560 MB/s
Write speed
490 MB/s
Memory type
TLC 3D NAND
Read latency
50 µs
Write latency
37 µs
Random write (100% span)
44500 IOPS
Random read (100% span)
96000 IOPS
Random write (8KB)
85000 IOPS
Random read (8KB)
48000 IOPS
Random write (4KB)
30000 IOPS
Random read (4KB)
48000 IOPS

Product Details

Intel Evolving Storage Technology Intel® Solid State Drives (Intel® SSDs) continue to evolve with the introduction of the Intel® SSD 535 Series. Designed for a wide range of consumer and embedded platforms, including Ultrabook™, traditional desktops and laptops, mini computers, and digital signage, as well as the latest tablets and small form factor mobile systems, Intel SSD 535 Series combines high quality, reliable performance and low power consumption for space conscious computing. Small Form Factors The Intel SSD 535 Series M.2 form factor delivers outstanding performance for thin and light computing devices. Intel’s SSD M.2 form factor requires far less space than a traditional 2.5-inch form factor storage device. Intel SSD 535 Series is also available in traditional 2.5-inch form factors, providing a variety of solid state technology solutions. The Intel SSD 535 Series product line is available in capacities ranging from 56GB to 480GB. Latest NAND Technology Intel SSD 535 Series uses the latest 16nm NAND technology. You will also benefit from the high quality and reliability you’ve come to expect from Intel. Along with power and space savings, reliability, and peace of mind, the Intel SSD 535 Series comes with Intel’s outstanding customer support and 5-year limited warranty. A New Generation of Power Efficient Performance With the Intel SSD 535 Series, your computer will effortlessly manage demanding consumer client applications and easily handle intense multi-tasking. The Intel SSD 535 Series accelerates platform performance with sequential reads of up to 540 megabytes and sequential writes of up to 490 megabytes per second (MB/s) and random read and write input/output operations (IOPS) of up to 48K and 80K respectively. In addition to strong performance gains, Intel SSD 535 Series provides extended battery life through low power modes. Idle power consumption of Intel SSD 535 Series is reduced by >90% over a typical hard disc drive, thereby reducing power consumption from watts to milliwatts. When the Intel SSD 535 Series is coupled with a 4th or 5th generation Intel® Core-based platform, advanced power mode settings reduce power dissipation another order of magnitude – from milliwatts to microwatts. Product Spotlight - High performance for demanding applications; - High quality and reliability; - Low power consumption; - Space-conscious form factors; - 16nm NAND technology; - Wide range of capacities.
