HPE AP-505H

Best offer
AED
1 46319

Key Features

  • 2.4 GHz: Yes
  • 5 GHz: Yes
  • 6 GHz: No
  • Maximum data transfer rate (2.4 GHz): 287Mbit/s
  • Maximum data transfer rate (5 GHz): 1200Mbit/s
  • Antenna features: Integrated antenna
  • Antenna direction type: Semi-directional
  • Antenna gain level (max): 5.4dBi
  • Maximum data transfer rate: 1487Mbit/s
  • Placement: Ceiling, Table, Wall
  • Antenna connector type: RP-SMA
  • Antenna type: Internal
  • Auto MDI/MDI-X: Yes
  • MIMO type: Multi User MIMO
  • Ethernet LAN data rates: 10, 100, 1000Mbit/s
  • Offers
  • Price History
  • Specifications
  • Product Details
  • Review IconReviews

Specifications

Features

Antennas quantity
2
Trusted Platform Module (TPM)
✓
Security algorithms
WPA, WPA2, WPA3
Bluetooth version
5.0
MIMO
✓
Product colour
White
Antenna gain level (max)
5.40 dBi
Maximum data transfer rate
1487 Mbit/s
Placement
Ceiling, Table, Wall
Antenna connector type
RP-SMA
Maximum data transfer rate (5 GHz)
1200 Mbit/s
Maximum data transfer rate (2.4 GHz)
287 Mbit/s
5 GHz
✓
6 GHz
✗
2.4 GHz
✓

Packaging data

Package weight
645 g
Package height
63 mm
Package depth
183 mm
Package width
193 mm

Weight & dimensions

Weight
360 g
Height
150 mm
Depth
47 mm
Width
86 mm

Power

Power consumption (max)
50 W
Power over Ethernet (PoE)
✓

Other features

Cable lock slot type
Kensington

Design

Cable lock slot
✓
Antenna direction type
Semi-directional

Computer system

Antenna type
Internal

Network

Bluetooth
✓
Networking standards
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3bz
Auto MDI/MDI-X
✓
MIMO type
Multi User MIMO
Ethernet LAN data rates
10, 100, 1000

Ports & interfaces

USB connector type
USB Type-A
Ethernet LAN (RJ-45) ports
5
USB 2.0 ports quantity
1

Operational conditions

Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
5 - 93 %
Storage relative humidity (H-H)
5 - 93 %

Technical details

Certification
None
Spread spectrum method
OFDMA
Compliance certificates
Low Voltage Directive (LVD)

Antenna

Antenna features
Integrated antenna

Logistics data

Harmonized System (HS) code
85176990

Radar

Modulation
1024-QAM, 16-QAM, 256-QAM, 64-QAM, BPSK, CCK, QPSK

Product Details

HPE Aruba Networking 500H Series Unified Hospitality Access Points delivers cost-effective Wi-Fi 6 coverage in a compact form factor that is ideal for hotels, residence halls, and remote offices. With 1.5 Gbps maximum combined speed, Zero Touch Provisioning, and wired ports, the 500H Series is ready to improve wireless experiences for guests, employees, students, and teleworkers. The 500H Series is Wi-Fi CERTIFIED™ and supports 802.11ax features: OFDMA for multi-user efficiency, target wake time (TWT) to extend the battery life of connected IoT devices, and WPA3 and Enhanced Open for greater password and guest security. The 500H Series includes a limited lifetime warranty. What is new supporting point: The AP provides supports for OFDMA for enhanced multi-user efficiency, and WPA3 and Enhanced Open for greater security. Cost-effective Wi-Fi 6 hospitality access points provide up to 1.5 Gbps maximum combined data rate with a range of connectivity options for venues such as hotels, residence halls, and remote offices. Zero Touch Provisioning that provides ease of implementation in branch offices and remote sites, without on-site technical expertise. You can customize deployment with optional desktop stand and models that offer choice of wired connectivity, USB, and PoE out support. Dynamic Segmentation and policy enforcement firewalls (PEF) automatically enforce consistent policies across all networks, enhancing user and device security. The AP provides IoT-ready Bluetooth 5 and Zigbee support.
