Moxa EDS-510E-3GTXSFP 10-ports

Name: Moxa EDS-510E-3GTXSFP 10-ports
Brand: Moxa
SKU: 345944
Availability: InStock

Best offer

AED

3 882⁰⁰

Key Features

Switch layer: L2
Basic switching RJ-45 Ethernet ports quantity: 7
Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
DHCP features: DHCP Option 66, DHCP Option 67, DHCP option 82, DHCP client, DHCP server
Half duplex: Yes
Wall mountable: Yes
Queue scheduling algorithms: Priority queuing (PQ)
Full duplex: Yes
DIN rail mounting: Yes
MAC address table: 8000entries
Power source: DC
USB 2.0 ports quantity: 1
SSH/SSL support: Yes
BPDU filtering/protection: Yes
Broadcast storm control: Yes

Specifications

Features

Mean time between failures (MTBF)

725532 h

Product colour

Black

Packet buffer memory

1 MB

Wall mountable

✓

Queue scheduling algorithms

Priority queuing (PQ)

Full duplex

✓

DIN rail mounting

✓

MAC address table

8000 entries

Switch layer

Weight & dimensions

Weight

1690 g

Height

135 mm

Depth

116 mm

Width

79.20 mm

Power

Power protection features

Overload, Reverse polarity

DC input voltage

24 V

Input current

0.68 A

Power source

Design

International Protection (IP) code

IP30

Housing material

Metal

LED indicators

Yes

Network

Networking standards

IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z

Management protocols

LLDP Back Pressure Flow Control BOOTP Port Mirror DHCP Option 66/67/82 DHCP Server/Client Fiber check Flow control IPv4/IPv6 RARP RMON SCP SMTP SNMP Inform SNMPv1/v2c/v3 Syslog Telnet TFTP

Half duplex

✓

Ports & interfaces

USB 2.0 ports quantity

Basic switching RJ-45 Ethernet ports type

Fast Ethernet (10/100)

Basic switching RJ-45 Ethernet ports quantity

Operational conditions

Storage relative humidity (H-H)

5 - 95 %

Technical details

Certification

Air: 15 kV IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m IEC 61000-4-4 EFT: Power: 4 kV, FCC Part 15B Class A IEC 61000-4-2 ESD: Contact: 8 kV, Signal: 4 kV IEC 61000-4-5 Surge: Power: 4 kV, Signal: 4 kV IEC 61000-4-6 CS: 10 V IEC 61000-4-8 PFMF ATEX Class I Division 2 DNV-GL LR ABS NK IEC 61850-3 IEEE 1613 EN 50121-4 NEMA TS2 IEC 60068-2-27 IEC 60068-2-32 IEC 60068-2-6, UL 508 EN 61000-6-2/-6-4 CISPR 32

Switch type

Managed

Security

SSH/SSL support

✓

BPDU filtering/protection

✓

Broadcast storm control

✓

DHCP features

DHCP Option 66, DHCP Option 67, DHCP option 82, DHCP client, DHCP server

Product Details

Moxa's Layer 2 managed switches feature industrial-grade reliability, network redundancy, and security features based on the IEC 62443 standard. We offer toughened, industry-specific products with multiple industry certifications, such as parts of the EN 50155 standard for rail applications, IEC 61850-3 for power automation systems, and NEMA TS2 for intelligent transportation systems.

Files

Product Brochure

mmo_68772896_1692364345_8937_6130.pdf

PDF• 917.1 KB
