TP-Link TL-WR844N
Best offer
AED
6300
Key Features
- DSL WAN: No
- 3G/4G USB modem compatibility: No
- 3G: No
- 4G: No
- Firewall: Yes
- Port triggering: Yes
- WLAN data transfer rate (first band): 11Mbit/s
- WLAN data transfer rate (max): 300Mbit/s
- WLAN data transfer rate (second band): 54Mbit/s
- WLAN data transfer rate (third band): 300Mbit/s
- Supports ISDN connection: No
- Number of guest networks (2.4 GHz): 1
- Top Wi-Fi standard: Wi-Fi 4 (802.11n)
- Guest access: Yes
- Antenna design: External
Specifications
Features
Compatible operating systems
2000, Linux., MAC OS, Microsoft Windows 98SE, NT, NetWare, UNIX, Vista, Windows 7, XP
Antennas quantity
2
Supported protocols
DDNS, VPN
Universal Plug and Play (UPnP)
✓
Quality of Service (QoS) support
✓
Frequency range
2.40 - 2.48 GHz
On/off switch
✓
Security algorithms
128-bit WEP, 152-bit WEP, 64-bit WEP, IPSec, SSID, WDS, WEP, WPA, WPA-Enterprise, WPA-PSK, WPA2, WPA2-Enterprise, WPA2-PSK, WPS
Rack mounting
✗
Product colour
White
DHCP client
✓
DHCP server
✓
Antenna connector type
RP-SMA
Frequency band
2.4 GHz
Antenna gain level (max)
5 dBi
Product type
Tabletop router
Port forwarding
✓
Packaging data
Package weight
430 g
Package height
86 mm
Package depth
202 mm
Package width
288 mm
Weight & dimensions
Height
33 mm
Depth
130 mm
Width
192 mm
Management features
Web-based management
✓
WPS push button
✓
Power
Power requirements
0.85A
Output current
0.60 A
Output voltage
9 V
Input current
0.6 A
Power over Ethernet (PoE)
✓
Power source type
DC
Input voltage
9 V
Performance
Top Wi-Fi standard
Wi-Fi 4 (802.11n)
Wireless LAN features
VPN support
PPTP
Dynamic DNS (DDNS)
✓
Guest access
✓
Number of guest networks (2.4 GHz)
1
WLAN data transfer rate (third band)
300 Mbit/s
WLAN data transfer rate (max)
300 Mbit/s
WLAN data transfer rate (second band)
54 Mbit/s
WLAN data transfer rate (first band)
11 Mbit/s
System requirements
Windows operating systems supported
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 2000, Windows 2000 Professional, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows 98, Windows 98SE, Windows NT, Windows Vista, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Other features
Mac compatibility
✓
Parental control
✓
WLAN data transfer rates supported
11, 54
Filtering
✓
Filtering description
Domain, IP, IP/Domain, MAC
Frequency range
2.4 - 2.4835 GHz
xDSL connection
✗
Software
Firewall security
SPI Firewall
Firewall
✓
Design
Reset button
✓
LED indicators
LAN, Link, Power, WAN, Yes
Transmit power
20 dBmW
Detachable antenna(s)
✓
Computer system
Processor cores
1
Built-in processor
✓
Packaging content
Quick start guide
✓
Manual
✓
Cables included
LAN (RJ-45)
AC adapter included
✓
Quick installation guide
✓
Network
Networking standards
IEEE 802.11b, IEEE 802.11g, IEEE 802.11h, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Supported network protocols
FTP, IPv4, IPv4 & IPv6, IPv6, L2TP, PPPoE, PPTP
VPN tunnels quantity
5
Wi-Fi band
Single-band (2.4 GHz)
Cabling technology
10/100Base-T(X)
Ethernet LAN data rates
10
Wi-Fi standards
802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN
✓
URL filtering
✓
Mobile network connection
✗
SIM card slot
✗
Ethernet LAN interface type
Fast Ethernet
VPN Passthrough
✓
Port triggering
✓
Ports & interfaces
DC-in jack
✓
Memory card slot(s)
✗
Ethernet LAN (RJ-45) ports
4
USB port
✗
USB ports quantity
1
Ethernet WAN
✓
USB 2.0 ports quantity
1
Supports ISDN connection
✗
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
10 - 90 %
Storage relative humidity (H-H)
5 - 90 %
Technical details
Sustainability compliance
✓
Certification
CE, FCC, RoHS
Compliance certificates
CE, Federal Communications Commission (FCC), RoHS
Security
Stateful Packet Inspection (SPI)
✓
IP address filtering
✓
MAC address filtering
✓
DMZ support
✓
DoS attack prevention
✓
Antenna
Antenna design
External
Receiver
Receiver sensitivity
270M: -68dBm@10% PER
130M: -68dBm@10% PER
108M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -90dBm@8% PER
Mobile network
3G
✗
4G
✗
WAN connection
WAN connection type
RJ-45
3G/4G USB modem compatibility
✗
DSL WAN
✗
Radar
Modulation
16-QAM, 64-QAM, CCK, DBPSK, DQPSK, OFDM
Product Details
Highlights:
- 300Mbps wireless transmission rate ideal for both bandwidth sensitive tasks and basic work;
- Easy wireless security encryption at a push of WPS button;
- IP based bandwidth control allows administrators to determine how much bandwidth is allotted to each PC;
- WDS wireless bridge provides seamless bridging to expand your wireless network.
What This Product Does
The 300Mbps Wireless N Router TL-WR840N is a combined wired/wireless network connection device designed specifically for small business and home office networking requirements. The TL-WR840N creates an exceptional and advanced wireless performance, making it ideal for streaming HD video, VoIP and online gaming. Also, Wi-Fi Protected Setup (WPS) button on the sleek and fashionable exterior ensures WPA2 encryptions, preventing the network from outside intrusions.
300Mbps Wireless N Speed - Fast Download Speed
TP-LINK’s TL-WR840N is a high speed solution that is compatible with IEEE 802.11b/g/n. Based on 802.11n technology, TL-WR840N gives users wireless performance at up to 300Mbps, which can meet your most demanding home networking needs, such as HD streaming, online gaming and large files downloading.
CCA Technology - Stable Wireless Signals
Clear Channel Assessment (CCA) automatically avoids channel conflicts using its clear channel selection feature and fully realizes the advantages of channel binding, greatly enhancing wireless performance.
IP QoS -- Manage your Bandwidth
Within the wireless network, indiscriminate Internet surfing and bandwidth-guzzling downloads by internal users often leave homes or small offices with insufficient bandwidth. TL-WR840N supports an IP QoS function, allowing optimum utilization of bandwidth and offering bandwidth control over congestion, preventing bandwidth abuse. In this way, users of a small network receive committed and specific bandwidth, preventing non-critical applications from degrading network performance.
Easy To Use
With the TL-WR840N even novice users can setup their networks. The device comes with a CD featuring an Easy Setup Assistant that leads users through the setup process step-by-step, and even helps with wireless network settings and security configurations.
Features:
- Wireless N speed of up to 300Mbps makes it ideal for bandwidth consuming or interruption sensitive applications like video streaming, online gaming and VoIP;
- 2T2R MIMO™ delivers greater throughput at range versus conventional 1T1R;
- Easily setup a WPA encrypted secure connection at a push of the QSS button;
- WDS wireless bridge provides seamless bridging to expand your wireless network;
- QoS function assures the quality of VoIP and multimedia streaming;
- Wi-Fi On/Off Button allows users to simply turn their wireless radio on or off;
- Features parental control function managing the internet access of children or employee's computer;
- Supports virtual server, special application and DMZ host ideal for creating a website within your LAN;
- Offers Auto-mail function for system log, convenient for managing the router;
- Backward compatible with 802.11b/g products;
- Easy Setup Assistant provides quick & hassle free installation;
- Sleek exterior, can be mounted on a wall or placed horizontally on a table or desk.
Files
User manual
mmo_30226267_1563952884_3251_6475.pdf
PDF• 2 MB
Product Brochure
mmo_30226267_1563952968_2055_21159.pdf
PDF• 551 KB
