1. Video Input: 8 channels
2. Video Output: 1 HDMI, 1 VGA
3. Compression Format: H.265/H.264/Smart264
4. Encoding Capacity: 8 channels, 5 megapixel, 25 frames per second
5. Decoding Capacity: 1 channel, 5 megapixel, 25 frames per second (main stream), 8 channels, D1, 25 frames per second (auxiliary stream)
6. Decoding Format: H.265, H.264
7. Audio: Supports two-way audio
8. Audio Output: HDMI and 1 AUX audio output
9. Decoding Format: G.711U, AAC
10. Hard Drive Port: 1 x SATA
11. Hard Drive Capacity: Maximum 16TB
12. Recording Mode: Scheduled Recording, Alarm Recording
13. Playback Mode: Regular Playback, App Playback
14. Backup Mode: Regular Backup
15. WiFi: 2.4G, supports only Srihome standard cameras
16. WAN Port: RJ45 wired connection
17. Network Services: Supports DHCP, DNS, DDNS, NTP, UPNP, etc.
18. Alarm Modes: Motion Detection, Human Detection
19. Alarm Alerts: App Push, Alarm Whistle
20. Network Port: RJ45
21. USB Port: 2 x USB 2.0
22. Main Processor: Multi-core high-speed processor
23. Sensor: 1/3-inch, 5MP HD color CMOS sensor
24. Compression Format: H.264
25. Lens Specifications: Focal Length: 4mm
26. Viewing Angle: D: 110 degrees, H: 80 degrees, V: 58 degrees
27. Resolution: 1920P (2560x1920), VGA (480x360)
28. Frame rate: 15 frames per second
29. IR cutoff: Built-in IR cutoff, no color cast indoors or outdoors
30. Audio: Built-in microphone and speaker, supports two-way audio
31. Protocol: G711
32. Alarm Mode: Default black and white night vision. When an alarm is detected, the white light turns on and switches to full-color night vision.
33. White Light Mode: Turns on full-color night vision with adjustable brightness. The on-time can be customized via the app. Default time: 5:00 PM to 8:00 AM.
34. Infrared Mode: Disables white light and switches to standard night vision.
35. Alarm Mode: Motion detection, human presence.
36. Customizable Alarm Zones: Customizable motion detection zones for improved alarm accuracy.
37. Wireless: 2.4G (only connected to NVS001/NVS010 host).
Functions:
1. 5MP HD camera, supports 8 simultaneous channels.
2. NVR supports up to 8 5MP wireless cameras.
3. Supports up to 16TB hard drives (2.5-inch) for storage and playback.
4. Supports wireless bridge mode with a WiFi range of up to 60 meters.
5. Supports H.265 compression format, with approximately 15 days of storage per 1TB.
6. Supports two-way voice intercom, infrared dual-light, and full-color night vision.
7. AI Intelligence: Supports human tracking and siren alarms.
8. Supports mobile remote monitoring, intercom, and playback.
9. IP66 waterproof rating, suitable for indoor and outdoor use.
