REVODATA PSE5502G - 48V 30W IEEE802.3af/at 10/100/1000Mbps

Overview： Unmanaged model, plug and play, no configuration required, easy to use. POE injector provides a simple, economical, high-performance, intelligent solution for POE power over Ethernet and data communication. Under the condition that the power supply cannot be provided remotely, the traditional power line network can be expanded, the use of power lines can be reduced, and the construction cost and maintenance cost of the project can be effectively reduced. Features: Unmanaged Model, Plug and Play, no configuration required. Convert low voltage 12/18/24/48V to high 48V voltage. Support IEEE802.3af/at standard, 10/100/1000Mbps Gigabit data transmission. Support isolation circuit protection, short circuit protection, over voltage protection. auto-detects power supply from PSE power supply module. suitable for hotels, campuses, factory dormitories Specifications: Model: PSE5502G Transfer Rate: 10/100/1000Mbps Power Input: DC 12V, 18V, 24V, 48V PoE Output Voltage: DC 48V POE Output Power: 30W (IEEE 802.3at) POE power supply core :1/2- 3/6+ Standard: IEEE 802.3 I, IEEE 802.3 u, IEEE 802.3 x, IEEE 802.3 af, IEEE 802.3 at Temperature: Work within -40~75° Dimension: 81mm*77mm*26mm(L*W*H) Weight:155g Package Content: Industrial POE Injector*1 (PSE5502G)
