Mikrotik RB1100AHx4 - 7.5Gbps

Name: Mikrotik RB1100AHx4 - 7.5Gbps
Brand: Mikrotik
SKU: 345327
Availability: InStock

Best offer

AED

1 320⁰⁰

Key Features

DSL WAN: No
3G/4G USB modem compatibility: No
Throughput: 7.5Gbit/s
Processor threads: 4
Voltage monitoring: Yes
Throughput: 7.5 Gbit/s
Temperature monitoring: Yes
Storage media: Flash
Antenna type: Not supported
Cabling technology: 10/100/1000Base-T(X)
Ethernet interface type: Gigabit Ethernet
Ethernet LAN: Yes
SIM card slot: No
Ethernet LAN data rates: 10, 100Mbit/s
Ethernet WAN: Yes

Specifications

Features

Internal memory

1000 MB

Operating system installed

RouterOS

Processor frequency

1400 MHz

Rack mounting

✓

Rack capacity

Product colour

Stainless steel

Voltage monitoring

✓

Throughput

7.50 Gbit/s

Weight & dimensions

Height

47 mm

Depth

148 mm

Width

444 mm

Management features

Web-based management

✓

Firmware upgradeable

✓

Power

AC input voltage

100 - 240 V

Power consumption (typical)

20 W

Power over Ethernet (PoE)

✓

Power source type

Other features

Throughput

7.5 Gbit/s

Ergonomics

Temperature monitoring

✓

Storage

Compatible memory cards

MicroSD (TransFlash)

Storage media

Flash

Design

LED indicators

Activity, Fault, Yes

Computer system

Processor cores

Built-in processor

✓

Processor model

Annapurna Labs Alpine AL21400

Antenna type

Not supported

Packaging content

Cables included

AC, SATA

Network

Networking standards

IEEE 802.3af, IEEE 802.3at

Cabling technology

10/100/1000Base-T(X)

Ethernet interface type

Gigabit Ethernet

Ethernet LAN

✓

SIM card slot

✗

Ethernet LAN data rates

10, 100

Ports & interfaces

DC-in jack

✓

RS-232 ports

Ethernet LAN (RJ-45) ports

Ethernet WAN

✓

Processor

Processor threads

Memory

Flash memory

128 MB

Security

IP address filtering

✓

Logistics data

Harmonized System (HS) code

85176990

WAN connection

3G/4G USB modem compatibility

✗

DSL WAN

✗

Product Details

New RB1100AHx4 Dude Edition has Annapurna Alpine AL21400 CPU with four Cortex A15 cores clocked at 1.4GHz each, for a maximum throughput of up to 7.5Gbps. The device supports IPsec hardware acceleration and is faster at it than any previous RouterBOARD device (up to 2.2Gbps with AES128). Unit comes with 1U rackmount case, 13x Gigabit Ethernet ports, RS232 serial port and dual redundant power supplies (with -48v DC telecom power and 802.3at/af support). The RB1100AHx4 Dude edition features several high speed storage connectors (two SATA and two M.2) for using a Dude database, proxy cache or any other storage intensive feature. It includes a 60GB M.2 drive already installed.

Files

Product Brochure

mmo_39197007_1546945866_9999_32716.pdf

PDF• 837.8 KB
