Kasda Networks KW5515 - 300Mbps 802.11b/g/n

IMPORTANT TIPS: 1. Before login to the router for setup, make sure your Smartphone is already CONNECTED to the router's SSID successfully, if not, you MAY NOT be able to open the login website. 2. If you are using a CABLE Service, you must REBOOT the CABLE MODEM after finished router setup, otherwise the router CANNOT obtain IP address from the cable modem and you MAY NOT have internet connection. Setup Instruction: STEP 1: Use your Smartphone to search the Router’s SSID “Kasda XXXX KW5515” and connect to it. STEP 2: Open a browser on your Smartphone and login to the setup page. STEP 3: Follow the Quick Setup guide to finish all the settings. STEP 4: Reboot both your modem and Kasda router Specifications: Hardware Physical Interface: 4*10/100Mbps for LAN & 1*10/100Mbps for WAN Buttons: Reset, WPS LED Indicators: Power, WAN, LAN1/2/3/4, WPS, WiFi Antenna: 2*External 5dBi Fixed Antennas Power: Input: 100-240V AC, 50Hz; Output: 12V/0.5A Memory: 4MB Flash, 32MB RAM Processor: MTK >>Software WAN Connection Types: DHCP/Static IP/PPPoE DHCP: Server, Client, DHCP Client List, Address Reservation, DHCP Relay Management Support: Web Based GUI, FTP /HTTP /Telnet, Command Line Interface, Diagnostic Test, Firmware Upgrade-able, Remote Access Control Wireless Wireless Standards: IEEE 802.11b/g/n Frequency: 2.4GHz Wireless Speed: 2.4GHz up to 300Mbps Transmit Power: up to 20dBm Wireless Security: 64/128-bit WEP, WPA-PSK/WPA2-PSK/TKIP/AES Guest Network: 2.4GHz WiFi Guest network Others Compatible OS: Windows 10/8/7/vista/XP, Mac, Android, iOS Packing List: * N300 Wifi Router x1 * RJ-45 Ethernet Cable x1 * Quick Setup Manual x1 * US Standard 100-240V Power Adapter x1
