HPE AP-535

Name: HPE AP-535
Brand: HPE
SKU: 348344

Best offer

AED

985¹⁷

Key Features

2.4 GHz: Yes
5 GHz: Yes
Maximum data transfer rate (2.4 GHz): 1148Mbit/s
Maximum data transfer rate (5 GHz): 2402Mbit/s
Antenna features: Integrated antenna
Antenna direction type: Omni-directional
Antenna gain level (max): 5.4dBi
Maximum data transfer rate: 3550Mbit/s
Placement: Ceiling, Wall
Antenna type: Internal
Auto MDI/MDI-X: Yes
MIMO type: Multi User MIMO
Ethernet LAN data rates: 100, 1000, 2500Mbit/s
USB 2.0 ports quantity: 1
Spread spectrum method: DSSS

Specifications

Features

Antennas quantity

Security algorithms

WMM, WPA, WPA2

MIMO

✓

Product colour

White

Antenna gain level (max)

5.40 dBi

Maximum data transfer rate

3550 Mbit/s

Placement

Ceiling, Wall

Maximum data transfer rate (5 GHz)

2402 Mbit/s

Maximum data transfer rate (2.4 GHz)

1148 Mbit/s

5 GHz

✓

2.4 GHz

✓

Weight & dimensions

Weight

1270 g

Height

57 mm

Depth

240 mm

Width

240 mm

Power

Power consumption (max)

23.30 W

Power over Ethernet (PoE)

✓

Other features

Cable lock slot type

Kensington

Design

Cable lock slot

✓

Antenna direction type

Omni-directional

Computer system

Antenna type

Internal

Network

Networking standards

IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3z

Auto MDI/MDI-X

✓

MIMO type

Multi User MIMO

Ethernet LAN data rates

100, 1000, 2500

Ports & interfaces

USB connector type

USB Type-A

Ethernet LAN (RJ-45) ports

USB 2.0 ports quantity

Operational conditions

Operating temperature (T-T)

0 - 50 °C

Operating relative humidity (H-H)

5 - 93 %

Storage relative humidity (H-H)

5 - 93 %

Technical details

Certification

None

Spread spectrum method

DSSS

Antenna

Antenna features

Integrated antenna

Logistics data

Harmonized System (HS) code

85176990

Radar

Modulation

1024-QAM, 16-QAM, 256-QAM, 64-QAM, BPSK, CCK, QPSK

Product Details

The HPE Aruba Networking 530 Series Campus Access Points provide Wi-Fi 6 connectivity for high-density deployments such as larger office spaces, training and meeting facilities, and hospitals. Providing up to 2.97 Gbps combined aggregate data rate, this series is built on Wi-Fi 6 standards (IEEE 802.11ax) and includes features such as OFDMA, bidirectional MU-MIMO, and target wait time (TWT) for better multi-user performance and improved efficiency. This series can be deployed using Zero Touch Provisioning, without on‑site technical expertise, for ease of implementation in branch offices and for remote work. HPE Aruba Networking Central provides a single pane of glass for overseeing wired and wireless LANs, WANs, and VPNs. AI‑powered analytics, end‑to‑end orchestration and automation, and advanced security features are built natively into the solution. The 530 Series includes a limited lifetime warranty. What is new supporting point: Dual radio AP supporting 5 GHz and 2.4 GHz bands (4x4 MIMO). Protects network security with stronger encryption and authentication, secure credentials/keys storage, and user and IoT access policy enforcement firewalls (PEF). Wi-Fi 6 access points (APs) provide up to 2.97 Gbps combined aggregate data rate. IoT-ready with support for ^[1] Bluetooth 5 and Zigbee and two 5 Gbps ports for fast wired connectivity. Deploy models with internal antennas or connectorized models that support external antennas to meet range of environments.

Boost your Wi-Fi 6 Performance

The HPE Aruba Networking 530 Series Campus Access Points are designed to simultaneously serve multiple clients and traffic types providing up to 2.97 Gbps combined aggregate data rate. Dual-radio (dual 4x4 MIMO) 802.11ax AP with up-and downlink OFDMA and Multi-User MIMO (MU-MIMO). The AP includes features such as OFDMA, bidirectional MU-MIMO, and target wait time (TWT) for better multi-user performance and improved efficiency. Enhanced wireless experience with HPE Aruba Networking ClientMatch technology removes sticky client issues by steering a client to the AP where it it receives one of the best radio signals. Two 5 Gbps ports provide flexibility to support speeds of 1, 2.5, or 5 Gbps (or 100 Mbps).

Security By Design

The HPE Aruba Networking 530 Series Campus Access Points offer enhanced security with Dynamic Segmentation to remove the time-consuming and error-prone task of managing complex and static VLANs, ACLs, and subnets by dynamically assigning policies and keeping traffic protected and separated. It offers stronger encryption and authentication with WPA3, protected credentials/keys storage for guest access with Enhanced Open, and user and IoT access policy enforcement firewalls (PEF). The AP simplifies policy enforcement by using the PEF to encapsulate all traffic from the AP to the gateway (or mobility controller) for end-to-end encryption and inspection. For enhanced device assurance, the 530 Series include an installed Trusted Platform Module (TPM) for protected storage of credentials and keys, and boot code.

IoT Ready

The HPE Aruba Networking 530 Series Campus Access Points can serve as IoT platforms that bolster network security and provide coverage for a range of IoT devices without the need for network overlays. The AP supports an integrated Bluetooth 5 and 802.15.4 radio (for Zigbee support), as well as a USB port for increased flexibility, providing better security and reliable connectivity for IoT devices. HPE Aruba Networking Central Client Insights uses deep packet inspection to provide additional context and behavioral information that help verify devices are receiving proper policy enforcement and continuously monitor for rogue devices.

Sustainability

The HPE Aruba Networking 530 Series Campus Access Points support AI-powered Dynamic Power Save mode that , it enables APs to automatically wake up at a schedule when connectivity demand arises, reducing power demands and lowering the energy footprint. The Intelligent Power Monitoring (IPM) provides the ability to enable or disable capabilities based on available PoE power. The target wake time (TWT) establishes a schedule for when clients need to communicate with an AP to help improve client power savings and reduce airtime contention.
