CB (IEC 60950-1: 2005 + Am 1: 2009 + Am 2: 2013), CE-EMC (EN 55032: 2015, CE-LVD (EN 60950-1: 2005 + Am 1: 2009 + Am 2: 2013), EN 50130-4: 2011 +A1: 2014), EN 61000-3-2: 2014, EN 61000-3-3: 2013, FCC (47 CFR Part 15, KC (KN 32: 2015, KN 35: 2015)
UL (UL 60950-1), LOA (IEC/EN 60950-1)
CE-RoHS (2011/65/EU), RCM (AS/NZS CISPR 32: 2015), Reach (Regulation (EC) No 1907/2006), Subpart B), WEEE (2012/19/EU)
Removable IR-cut filter
✓
Anti-flicker
✓
Compliance certificates
CE, Industry Canada (IC), Low Voltage Directive (LVD), REACH, RoHS, WEEE
Audio
Automatic gain control
✓
Built-in speaker(s)
✓
Lens system
Lens mount interface
M12
Minimum aperture number
1.20
Maximum aperture number
2
Number of lenses
1
Fixed focal length
2.80 mm
Detect distance (wide)
60 m
Observe distance (wide)
23.80 m
Identify distance (wide)
6 m
Identify distance
3.90 m
Noise reduction technology
3D noise reduction
Recognize distance
7.70 m
Observe distance
15.30 m
Video
Video compression formats
H.264, H.265, M-JPEG
Frame rate
30 fps
Smart IR
✓
Image quality adjustment
Brightness, Contrast, Saturation, Sharpness
Privacy masking
✓
Security
IP address filtering
✓
Privacy protection
✓
Audit log
✓
Heartbeat
✓
Digest authentication
✓
HTTPS encryption
✓
Camera
Day/night mode
✓
Gain control type
Auto
Back Light Compensation (BLC)
✓
Number of Privacy masking areas
4
Camera shutter speed
1/3 - 1/100000 s
Maximum operating distance
50 m
3D NR (Noise Reduction)
✓
Bit rate control
Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Region of Interest (ROI) encoding
✓
Total megapixels
2 MP
Number of cameras
1
Bit rate
32 Kbps - 8 Mbps
Analog signal format system
PAL
Signal-to-Noise Ratio (SNR)
52 dB
Sensor type
CMOS
Lens viewing angle, horizontal
103°
Progressive scan
✓
Full HD
✓
Wide Dynamic Range (WDR)
✓
Intelligent Video Surveillance (IVS) system features
Face detection, Scene change
Highlight Compensation (HLC)
✓
Digital Wide Dynamic Range (DWDR)
✓
Lens viewing angle, diagonal
110°
Lens viewing angle, vertical
50°
Camera tilt control
✓
Amplifier
Sample rates
8 - 16 kHz
Pan-tilt unit
Tilt angle range
0 - 90 °
Pan range
0 - 360 °
Image sensor
Maximum resolution
1920 x 1080 pixels
Minimum illumination
0 lx
Infrared (IR) cut-off filter
✓
Night vision
Night vision
✓
LED type
IR
Night vision distance
30 m
Infra-red wavelength
850 nm
Product Details
Dive into the cable-free frontier
Tired of being restricted by wires? Whether you’re out in the outdoors, at a busy construction site, or in a place that’s quickly set up for a short time, dealing with wires is such a hassle. Here, the Cable-Free Series of products is like a game-changer for video security. These brand-new products break free from the old ways and bring in a new era where you don’t have to worry about cables.
The EasyLink Wi-Fi Kit guarantees secure data storage and seamless device linkage, giving users peace of mind in different scenarios. Unlike traditional wiring that is time-consuming and messy, the EasyLink Power Line Communication (PLC) Kit uses existing electrical wiring as a communication medium, creating stable, wall-penetrating connections. The Always On Video (AOV) Solar Camera enables continuous recording with low power consumption, achieving full-time recording at low cost. With 4G cameras, no wires, no worry, perfectly suitable for outdoor locations. No cable, just be free!
Deep learning algorithm
The magic behind it all
As its name implies, Hikvision AcuSense Technology provides accurate sensing in security hardware. Empowered by deep learning algorithms, AcuSense technology distinguishes people and vehicles from other moving targets.
Human and vehicle intrusion
Spotlights the events that matter
The most common concerns in perimeter protection are trespassing and vehicle break-ins. AcuSense helps you to focus on these events in two ways: alarm will only trigger when the preset intrusion type takes place, and related videos are sorted by categories for easier search.
Accurate alarm for human and vehicle
You can focus on alarms triggered by humans and vehicles while false alarms triggered by small animals or other irrelevant objects are vastly reduced. Now you can enjoy this intelligent function with VCA or motion detection.
Visual and auditory warning
On-site response and deterrence methods using visual and customizable auditory warnings to add another layer of protection. Two-way audio function is now also available.
Search targets quickly by type
Video clips are sorted by human and vehicle categories, and object classification vastly improves search efficiency.
