HI TONE SOLAR SRBLT-60

AMPLIFIER MODEL NO. 1.SRBLT-60 Front Panel Function Power- Power switch.(Turn ON/OFF unit power). Volume- Main channel volume adjust knob. Selector- Audio input selector(Turn A/B unit input) HIGH- Main channel treble adjust knob. LOW-. Main channel bass adjust knob BAL- Main channel balance adjust knob. VOL- Main channel volume adjust knob. MIC1- Microphone input jack 1 MIC2- Microphone input jack 2 MIC1-VOL- Microphone channel 1 volume adjust knob. MIC 2-VOL- Microphone channel 2 volume adjust knob. M.HIGH Microphone treble adjust knob M.LOW Microphone bass adjust knob. ECHO REP- Microphone echo adjust knob. DELAY- Microphone delay adjust knob. BLETOOTH Mp3 audio receiver SD- Mp3 sd input jack. USB- Mp3 usb input jack. NEXT- Mp3 audio next. PREV- Mp3 audio prev PLAY- Mp3 audio play MODE- Sd/usb input. Rear panel function AUDIO INPUT A CD/VCD/DVD player audio jack B TUNER/TAPE player audio jack "SPEAKER OUTPUT " "L Main Left channel speaker output R Main Right channel speaker output" "SPEAKER OUTPUT " V LINE-COM and 100V/70V DC 12V INPUT """+"" DC12V/Power output ""+"" ""-"" DC12V/Power output ""-"""
