DSLRKIT Active PoE Splitter - 48V-52V 24Watt IEEE 802.3af IEEE 802.3at 10/100/1000Mbps

Note: POE splitter must be connected to POE switch, POE midspan or 48V~52V POE injector for proper operation. Maximum output power of 15 watts (DC12V1.25A) when used with standard IEEE802.3af PoE switch (or 802.3af PoE injector). Max.24Watt (DC12V2A) output power when used with standard IEEE802.3at PoE switch (or 802.3at PoE injector). Maximum output power of 24 watts (DC12V2A) when used with the 48V~52V non-standard passive PoE switches (or 48V~52V passive PoE injector) RJ45 Female POE Input Port: Compatible with IEEE 802.3af PoE Switch/in Power over Ethernet Support 48V Unsolicited Power PoE Switch Support 48V Unsolicited Power PoE Adapter Specifications: Complies with IEEE802.3af 12V1.25A 15W output Compliant with IEEE802.3at output 12V2A 24W Insulation: 2.5 kV. Input Power: DC44~57V Output Power: DC12V 2A POE Data and Power Port: RJ45 (IEEE802.3af/at PoE Compatible) Data port: RJ45 Power output port: DC 5.5 x 2.1mm plug Data transfer rate: 10/100/1000Mbps/2.5G Data pin: RJ45 pin 12345678 Devices will be detected before poe input Power pin: compatible with 1/2 (+/-), 3/6 (-/+) or 4/5 (+), 7/8 (-). Body size: 80 x 45 x 26 mm. DC Cable Length: 85mm RJ45 Modular Plug Cable Length: 155mm Weight: 68g Operating Temperature: -20℃~45℃ Storage Temperature: -30℃~70℃ Item Includes: 1 x 2.5G 12V2A Active PoE Splitter (5.5*2.1mm DC plug) 1 x RJ45 Modular Plug Cable 1 x 5.5 x 2.1mm DC Cable
