25KG Digital Servo - 1/12 1/10 Core Motor

CSHEN 25KG Digital Servo - 1/12 1/10 Core Motor

Name: CSHEN 25KG Digital Servo - 1/12 1/10 Core Motor
Brand: CSHEN
SKU: 408995

Best offer

AED

200⁹⁹

Specifications

Product Details

Specification: Item Name: 25KG Digital Servo Main Material: Aluminium, Copper Motor: Core Motor Pulse Width Range: 500~2500μsec Operating Temperature: -20℃-60℃ Operating Voltage: 4.8 - 7.4V Operating Speed(4.8V): 0.19sec/60° Operating Speed(7.4V):0.16sec/60° Stall torque(4.80V): 21kg/cm Stall torque(7.4V): 25kg/cm Working Frequency: 1500μs/330Hz No-load Current: 200mA/300mA Operating Degree: 180° Bearing Type: 2BB Size: 4 x 4 x 2 cm Weight: 69g Package Information: Size: 6.2 x 5.2 x 3.8 cm Weight: 87 g Package List: 1 x 25KG Digital Servo 1 x 25T Servo Arm 1 x Parts Kit
