BW Corp IPC-HFW3200S

1/3” 2Megapixel progressive scan Exmor CMOS H.264 & MJPEG dual-stream encoding 25/30fps@1080P(1920×1080) DWDR, Day/Night(ICR), 2DNR, AWB, AGC, BLC > Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS 6mm fixed lens (3.6mm,8mm optional) Max. IR LEDs Length 20m IP66, PoE Specification: Image Sensor 1/3” 2Megapixel progressive scan Exmor CMOS Effective Pixels 1920(H)x1080(V) Scanning System Progressive Electronic Shutter Speed Auto/Manual, 1/3~1/10000s Min. Illumination 0.1Lux/F1.2 (Color), 0.01Lux/F1.2(B/W);0Lux/F1.2(IR on) S/N Ratio >50dB Camera Features Max. IR LEDs Length 20m Day/Night Auto(ICR)/Color/B/W Backlight Compensation BLC / HLC / DWDR White Balance Auto Gain Control Auto/Manual Noise Reduction 2D Privacy Masking Up to 4 areas Lens Focal Length:3.6mm Max Aperture F1.6 Angle of View H: 46°(70°/35°) Lens Type Fixed lens Mount Type Board-in Type Video Compression H.264 / MJPEG Resolution 1080P(1920×1080) / 720P(1280×720) / D1(704×576) / CIF(352×288) Frame Rate Main Stream 1080P/720P(1 ~ 25/30fps) Sub Stream D1/CIF(1 ~ 25/30fps) Bit Rate H.264: 32K ~ 8192Kbps, MJPEG: 32K ~20480Kbps Network Ethernet RJ-45 (10/100Base-T) Protocol IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour ONVIF ONVIF Ver. 2.0 Max. User Access 10 users Smart Phone iPhone, iPad, Android, Windows Phone General Power Supply DC12V, PoE (802.3af) Power Consumption <6W Working Environment -10°C~+60°C, 10%~90% Ingress Protection: IP66
