be quiet! Pure Wings 2 - 120mm

Key Features

Number of fan blades: 9
Fan dimensions (W x D x H): 25 x 120 x 120mm
Rotational speed (max): 2000RPM
Maximum air pressure: 2.23mmH2O
Type: Fan
Bearing type: Rifle bearing
Noise level (high speed): 35.9dB
Airflow: 111.3m³/h
Maximum airflow: 65.51cfm
Safety current: 0.3Ah
Rated voltage: 12V
Compatible processor series: Not supported
Product colour: Black
Rated current: 0.2A
Suitable location: Computer case

Specifications

Features

Country of origin

China

Mean time between failures (MTBF)

80000 h

Screws included

✓

Pulse-width modulation (PWM) support

✓

Fan diameter

120 mm

Suitable location

Computer case

Supported processor sockets

Not supported

Product colour

Black

Rotational speed (max)

2000 RPM

Maximum air pressure

2.23 mmH2O

Type

Fan

Bearing type

Rifle bearing

Noise level (high speed)

35.90 dB

Airflow

111.30 m³/h

Maximum airflow

65.51 cfm

Number of fan blades

Packaging data

Package weight

158 g

Package height

28 mm

Package depth

155 mm

Package width

120 mm

Weight & dimensions

Weight

130 g

Height

25 mm

Depth

120 mm

Width

120 mm

Cable length

0.46 m

Fan dimensions (W x D x H)

120 x 120 x 25 mm

Power

Power consumption (typical)

1.08 W

Power supply

3.60 W

Voltage

5 - 12 V

Maximum current

0.09 A

Rated current

0.20 A

Safety current

0.30 Ah

Rated voltage

12 V

Other features

Airflow

111.3 m³/h, 87 m³/h

Packaging content

Number of screws

Ports & interfaces

Fan connector

3-pin

Technical details

Certification

CE, TÜV, UL

Processor

Compatible processor series

Not supported

Logistics data

Harmonized System (HS) code

84733080

Master (outer) case gross weight

10200 g

Master (outer) case height

290 mm

Master (outer) case length

410 mm

Master (outer) case width

320 mm

Product Details

"Pure Wings 2 – Outstanding Reliability and Silent Cooling. The Pure Wings 2 120mm fans bring famous be quiet! silent cooling to entry level computing, yet are also appropriate for gaming and multimedia systems. Combining outstanding reliability, quiet operation, and a great price-for-performance ratio, Pure Wings 2 120mm is unique in its class. They are the ultimate reason to put well-known be quiet! silent cooling in your PC." VERY QUIET OPERATION Achieves a great price-for-performance ratio The Pure Wings 2 120mm fan operates at only 19.2dB(A) even at maximum speed. The perfect choice for silent home and office PCs as well as gaming and multimedia systems. SILENCE-OPTIMIZED FAN BLADES For even better cooling Thanks to its surface-optimized fan blades the airflow is enhanced, noise-generating turbulences are minimized and the air pressure is increased. This feature is the key to effective cooling. RIFLE BEARING TECHNOLOGY Gives the fan a very long lifespan The Pure Wings 2 120mm is the hallmark of outstanding reliability. This is achieved by its high-quality rifle bearing technology, which assures a very long lifespan of up to 80,000 hours.

VERY QUIET OPERATION

The Pure Wings 2 120mm fan operates at only 19.2dB(A) even at maximum speed. The perfect choice for silent home and office PCs as well as gaming and multimedia systems.

SILENCE-OPTIMIZED FAN BLADES

Thanks to its surface-optimized fan blades the airflow is enhanced, noise-generating turbulences are minimized and the air pressure is increased. This feature is the key to effective cooling.

RIFLE BEARING TECHNOLOGY

The Pure Wings 2 120mm is the hallmark of outstanding reliability. This is achieved by its high-quality rifle bearing technology, which assures a very long lifespan of up to 80,000 hours.

Files

Performance curve

mmo_66918559_1547800840_5227_29191.pdf

PDF• 40.3 KB

Product Brochure

mmo_66918559_1547800919_3196_1461.pdf

PDF• 876.9 KB

Videos

Pure Wings 2

MP4• 1.9 MB

Pure Wings 2 PWM

MP4• 1.9 MB

Reviews

Join our newsletter

Be the first to know about new arrivals, sales, and exclusive picks

be quiet! Pure Wings 2 - 120mm

Key Features

Number of fan blades: 9
Fan dimensions (W x D x H): 25 x 120 x 120mm
Rotational speed (max): 2000RPM
Maximum air pressure: 2.23mmH2O
Type: Fan
Bearing type: Rifle bearing
Noise level (high speed): 35.9dB
Airflow: 111.3m³/h
Maximum airflow: 65.51cfm
Safety current: 0.3Ah
Rated voltage: 12V
Compatible processor series: Not supported
Product colour: Black
Rated current: 0.2A
Suitable location: Computer case

Offers (2)

2 offers

From

AED

Infinity

Be quiet! Pure Wings 2 120mm PWM Premium Low Noise Cooling Fan | Black | BL039

Unavailable

Price History

Loading price history...

Specifications

Features

Country of origin

China

Mean time between failures (MTBF)

80000 h

Screws included

✓

Pulse-width modulation (PWM) support

✓

Fan diameter

120 mm

Suitable location

Computer case

Supported processor sockets

Not supported

Product colour

Black

Rotational speed (max)

2000 RPM

Maximum air pressure

2.23 mmH2O

Type

Fan

Bearing type

Rifle bearing

Noise level (high speed)

35.90 dB

Airflow

111.30 m³/h

Maximum airflow

65.51 cfm

Number of fan blades

Packaging data

Package weight

158 g

Package height

28 mm

Package depth

155 mm

Package width

120 mm

Weight & dimensions

Weight

130 g

Height

25 mm

Depth

120 mm

Width

120 mm

Cable length

0.46 m

Fan dimensions (W x D x H)

120 x 120 x 25 mm

Power

Power consumption (typical)

1.08 W

Power supply

3.60 W

Voltage

5 - 12 V

Maximum current

0.09 A

Rated current

0.20 A

Safety current

0.30 Ah

Rated voltage

12 V

Other features

Airflow

111.3 m³/h, 87 m³/h

Packaging content

Number of screws

Ports & interfaces

Fan connector

3-pin

Technical details

Certification

CE, TÜV, UL

Processor

Compatible processor series

Not supported

Logistics data

Harmonized System (HS) code

84733080

Master (outer) case gross weight

10200 g

Master (outer) case height

290 mm

Master (outer) case length

410 mm

Master (outer) case width

320 mm

Product Details

VERY QUIET OPERATION

The Pure Wings 2 120mm fan operates at only 19.2dB(A) even at maximum speed. The perfect choice for silent home and office PCs as well as gaming and multimedia systems.

SILENCE-OPTIMIZED FAN BLADES

Thanks to its surface-optimized fan blades the airflow is enhanced, noise-generating turbulences are minimized and the air pressure is increased. This feature is the key to effective cooling.

RIFLE BEARING TECHNOLOGY

The Pure Wings 2 120mm is the hallmark of outstanding reliability. This is achieved by its high-quality rifle bearing technology, which assures a very long lifespan of up to 80,000 hours.
