Fitment: For RX 2016 2017 2018 2019
Feature:
1. Condition: WithSO-N-Y lens, six-layer lens,100% new products and high quality.
2. hard-resistant function, strong blowing
3. Easy installation and simple operation
4. High definition camera reading, high definition and wide viewing angles
5. Ensure safe driving to avoid accidents on vehicles
6.Stable performance, low power consumption, low noise,HD camera, adjustment, night vision effect
Main Specification:
Operating temperature: -20 ° C ~ 70 °
Video Color: Color
Lens materials: 100% Glass
Optical format: Aptina MT9V136
Typical type: High-sensitivity mode for low-light conditions (Night Vision)
Degree of protection: IP67 (Waterproof)
System format: NTSC (Default), PAL(optional, please leave message to us if you need, free cost)
Power supply: 6V/12/24VDC Wide Input
Field view angle: 170degree (Diagonal), 138degree (Horizontal), 125 degree(Vertical) (more information from Option 2)
Optical distortion: -88% (more information from Option 2)
Horizontal resolution: 520TV lines (Pixels)
Output: RGB 720H x 480V@NTSC, 720H x 582V@PAL
Parking line: Manual Parking Line ON/OFF
Image: Manual Switch Mirror & Normal Image
Working time Continuous working
Operation temperature: -40°C to +80°C (-40°F to 176°F)
Package Retail: gift box (available for camera size smaller than 15cm/5.9inch)
Note: Default order : NTSC version/system, If you want to order PAL version, please leave us message before order. This service is free, But it may need 2-4 working days for preparing.
Freight bill:
1 * front view
1 * 6m video cable
1 * power cable
1 * user manual
Parking Accessories Car Front Camera For RX 2016 2017 Waterproof Night Vision CCD high quality
red line, positive pole, connected to + 12V
(safe box / ACC / lighter position is OK)
black wire negative / ground
video plug, plug in the video input port of the display screen
digital rotary block, never heating, changing 12V voltage to 3.3V
1. After the installation of the central control navigation screen, Androld large screen,the car screen plus the function module protocol decoding box, in additionto the video input port used after reversing, there Is also reserved video input portdirectly before the installation Vision
2. If the central control navigation screen, Androld large screen and vehicle screen are equipped with function moduleprotocol decoding box, there Is only one way of reversing rear AUX Input port, which Is equipped withfront AUX camera, and two ways of video control box are needed
Enhanced Road Awareness: This car front camera provides a clear forward view, helping drivers detect obstacles and monitor road conditions. As a reliable vehicle dash camera, it improves safety and confidence, making driving easier in both city traffic and long trips
Clear and Stable Imaging: Built with dependable optics, the auto front view camera delivers and consistent video. Acting as part of a car video monitoring system, it captures detailed visuals that assist with safer navigation and effective accident recording
Durable and Weather-Ready: Made from sturdy, weather-resistant materials, this car electronics camera works reliably in different environments. As a trusted vehicle front lens, it resists rain, dust, and sunlight exposure, ensuring steady performance year-round
Practical Safety Upgrade: Easy to install, this driving recorder camera adds extra security to your car. As one of the useful car safety accessories, it supports safer manoeuvres, effective monitoring, and provides peace of mind for daily driving routines
