Cisco SF110D-16HP 16-ports

Key Features

Switch layer: L2
Basic switching RJ-45 Ethernet ports quantity: 16
Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
Number of queues: 4
Fast Ethernet (copper) ports quantity: 16
Switching capacity: 3.2Gbit/s
Full duplex: Yes
Jumbo frames support: Yes
Forwarding rate: 1.4Mpps
Form factor: 1U
Auto MDI/MDI-X: Yes
Head-of-line (HOL) blocking: Yes
Copper ethernet cabling technology: 100BASE-TX, 10BASE-T
10G support: No
Flow control support: Yes

Specifications

Features

Country of origin

China

Quality of Service (QoS) support

✓

Rack mounting

✓

Product colour

Black

Switching capacity

3.20 Gbit/s

Full duplex

✓

Jumbo frames support

✓

Forwarding rate

1.40 Mpps

Switch layer

Packaging data

Package weight

845.06 g

Package height

55.50 mm

Package depth

289.30 mm

Package width

232.80 mm

Weight & dimensions

Weight

467.20 g

Height

43.50 mm

Depth

160 mm

Width

90 mm

Management features

Web-based management

✗

Power

AC input voltage

100 - 240 V

Power plug type

Type C

DC input voltage

12 V

AC input frequency

50 Hz

Input current

1 A

Power over Ethernet (PoE)

✗

Input voltage

12 V

Design

LED indicators

Yes

Form factor

Packaging content

Quick Start guide

Quick start guide

✓

Power supply included

✓

Network

Networking standards

IEEE 802.1p, IEEE 802.3, IEEE 802.3af, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x

Auto MDI/MDI-X

✓

Head-of-line (HOL) blocking

✓

Copper ethernet cabling technology

100BASE-TX, 10BASE-T

10G support

✗

Flow control support

✓

Ports & interfaces

Power over Ethernet (PoE) ports quantity

Fast Ethernet (copper) ports quantity

Basic switching RJ-45 Ethernet ports type

Fast Ethernet (10/100)

Basic switching RJ-45 Ethernet ports quantity

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

10 - 90 %

Storage relative humidity (H-H)

5 - 90 %

Technical details

Certification

CE, CSA (CSA 22.2), FCC 15 (CFR 47) A, FCC B, UL (UL 60950)

Switch type

Unmanaged

Data transmission

Number of queues

Product Details

The SF110D-16HP Switch delivers basic network connectivity and reliability for small businesses, without complexity. This switch provides all of the features, expandability, and investment protection you expect from Cisco, with no installation software and nothing to configure. Just plug it in, connect your computers and other business equipment, and get to work.
