Steloproad 8 RJ45 + 2 SFP PoE Switch 8-ports

Overview：

This Mini Industrial 8 Port 10/100/1000Mbps Gigabit Ethernet POE+ Switch with 2 SFP Port supports 10/100/1000Base-T and 100/1000Base-X SFP Port. The Ethernet port supports both half-duplex and full-duplex mode. This industrial Ethernet PoE+ switch is designed to match the critical industrial standards. With reliable and simple operation against vibration and shock, and wide operation temperature range, it could match a variety of harsh environment. The switch also complies with CE and FCC standards, and passed the 100% burning test to ensure that it will fulfill the needs of industrial applications. It is a good choice for an economical solution for industrial Ethernet connections.

Features:

• 8 10/100/1000Base-TX + 2 1000Base-FX
• 10/100/1000Mbps RJ45 Port Supports Full/Half-duplex, Auto-negotiation, Auto MDI/MDIX
• Supports 802.3x Flow control
• 9K Bytes Jumbo Frame
• Supports Wall-mount and DIN-Rail installation
• -40°C to 75°C (-40°F to 167°F) operating temperature
• Redundant Power Inputs

Specifications:

• Standard: IEEE802.3 10Base-T Ethernet, IEEE802.3u 100Base-TX/FX Fast Ethernet, IEEE802.3ab 1000Base-T , IEEE802.3z 1000Base-SX/LX Gigabit Ethernet IEEE802. 3af (PoE), IEEE802. 3at (PoE+)
• Packet Buffer Memory: 2.75Mbit
• Max Packet Length: 9K Bytes.
• Address Table Size: 4K MAC Address
• Ethernet Port: RJ45 10/100/1000Mbps Gigabit Ethernet
• Optical Port: SFP - 1000Mbps
• Input Power: 12~48V DC
• Casing Material: Aluminum Case

Note: If you have any questions or find the Ethernet POE+ switch can’t use, please contact us. Our professional technical staff will teach you how to use or help you find the reason and solve it.
