Condition: 100% Brand NewItem Type: Driving Recorder
Color: As picture shown
Solution: for Hisilicon 3520 (V300) HD Solution
Operation Mode: Infrared Remote Control Operation
System Language: Simplified Chinese and English
Video Compression Format: H.264
OSD: Support Time, Date, Channel Characters, Display Border, Vehicle Information Overlay
Video Input: Support 4 Channels of 1080P, 960P, 720P HD AHD Video Input
Support 4 Channels CVBS Standard Clear Video Input
Compatible with CVBS and AHD Signals Mixed Input
Compatible with PAL and NTSC Two Standard Mixed Input
Video Output: 2-way Compound Video Output, 1 Channel VGA HD Output, 1 Channel CVBS standard definition output (AV Male)
Display Mode: 12 Multi-screen Display Modes, Support Each Channel Single Imagine Full Screen Display
Power on Screen: H Type, Field Type, Average Three Screen, Average Two Screen, Power off Memory Optional
Video Resolution: 1920x1080
Output Resolution: 1920x1080, 1280x720, 1024x768, 800x600
Video Quality: Super Clear, Hd, Standard, Ordinary Level 4 Video Adjustable
Video Mode: H Type, Field Type, Average Three Picture, Average Two Picture Optional (default Field Type);
Video Recording Mode: Automatic Video Recording on Power On, Vibration Video Recording on Stopping and Extinguishing, and 24h Video Recording on Extinguishing Delay;
Storage: Support 2G-256G TF Memory Card (Small TF Card)
Video Playback: Online Video Playback or Computer Playback (External USB Drive is Required to Backup Video Files)
Power Management: Adaptive Wide Voltage Input, Reverse Short Circuit Protection, Low Voltage Protection, High Voltage Protection and Other Protection Functions
Working Voltage: DC12V-36V
Power Consumption: Operating Temperature: -30℃-+70℃
Camera Specification:
Right and Left Side View: 200 Degrees x 2
Image Sensor: for Sony 225 HD Processor
Lens: 6g Full Glass Lens
Backlight
